Name: Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof
Brand: Paneltronics
SKU: 29828-cwr
Price: 62.00 CAD
Availability: OutOfStock

Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof

Roll over image to zoom in Click on image to zoom

Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers

Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers
UL Recognized (UL 1077) for use in th USA, and CSA Certified for use in Canada
Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
Handle Color - Metal with silicon rubber seal
Maximum Aperage - 50 Amps
Maximum Voltage/AIC - 32 VDC/2,500 amps with no back-up fuse (ABYC E-11.10.1.5.5)
Rated Switch Cycles - 10,000 actuations at rated current and voltage
Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker)
Optional Boot - Black silicone rubber (P/N 048-015)

Color = Stainless | Throw/Pole = SPST

Manufacturer Part Number: 206-051S

General Information

Manufacturer	Paneltronics
Manufacturer Part Number	206-051S
Product Type	Electrical \| Switches & Accessories
UPC	602290201404

Canada: Prices in CAD. Ships nationwide in 2–5 business days. GST/HST/PST calculated at checkout. Shipping policy.

Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof

Description

Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof
