Panduit DNF14-250FIM-L. Connector contacts plating: Nickel, Connector gender: Female, Product colour: Blue. Height: 22.9 mm. Quantity per pack: 50 pc(s)
The vibration resistant male tab disconnect is made of brass and is nickel-plated. It is fully insulated in a blue, nylon housing. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 16-14 AWG (1.5-2.5 mm²). It is 0.90" (22.9 mm) long and 0.42" (10.7 mm) wide. The disconnect has a funnel entry configuration and a butted seam barrel. It comes in bottles of 50.
General Information
Manufacturer
PANDUIT CORP
Manufacturer Part Number
DNF14-250FIM-L
Manufacturer Website Address
http://www.panduit.com
Brand Name
Panduit
Product Name
Terminal Connector
Product Type
Terminal Connector
UPC
074983521678
Product Color
Blue
Width
0.4"
Features
Flame Retardant
Environmentally Friendly
Yes
Warranty
Limited Warranty
1 Year
