Omnitron Systems iConverter 8786T-0 Transceiver/Media Converter - 1 x LC Ports - DuplexLC Port - Multi-mode - 3.11 Mile - AC Adapter - Rack-mountable
The iConverter RS422/485 is a managed serial RS-422 and RS-485 to fiber converter that transmits serial protocol over fiber media. The RS422/485 media converters operate inpairs, extending serial distances over fiber up to 120km, which improves noise immunity from electrical and magnetic interference.
The RS422/485 is available with a single-mode dual fiber, multimode dual fiber or single-mode single-fiber transceiver. The serial port interface is available with either a DB-9 female connector or terminal block connector for field wiring.
The RS422/485 automatically detects the data rate of connected Full-Duplex serial device, ranging from 110 bps to 921,600 bps. It also automatically adjusts to changes in the connected device's Full-Duplex data rate during operation without reconfiguration or interruption of service.
Half-Duplex RS-485 and Full-Duplex RS-485 (sometimes referred to as Multipoint RS-422) operations are supportedvia a configurable baud rate DIP-switch to match the master/
