Omnitron iConverter 1000FF - Media converter - GigE - 1000Base-X - ST single-mode / ST single-mode - up to 7.5 miles - 1310 nm
- 1000BASE-SX or 1000BASE-LX single-mode to multimode fiber converter
- Supports multimode, single-mode and single-fiber with SC connectors
- Supports distances up to 80km
- User-selectable link fault detection modes facilitate quick fault detection, isolation and reporting
- SNMP management via NetOutlook provides real-time port and module information, remote parameter configuration and trap notification
- Management is available with the addition of a management module to the chassis
- Modules are hot-swappable in 19-module, 5-module, 2-module or 1-module chassis
- LED displays for immediate visual status of each port
The iConverter 1000FF managed media converter is a member of the modular iConverter product family. The 1000FF provides single-mode to multimode fiber conversion and is a cost-effective solution to extending network distances by connecting multimode fiber network devices over single-mode fiber cabling.
iConverter 1000FF models feature SC connectors and are available with multimode, single-mode and single-fiber options. The single-mode fiber port supports distances up to 80km, and the multimode fiber port supports distances up to 550m. The 1000FF features user-selectable link propagate and remote fault detection modes to facilitate quick fault detection, isolation, and reporting.
iConverter 1000FF modules are hot-swappable and can be mounted in a 19-module (2U high) or 5-module (1U high) rack-mountable chassis (19-inch or 23-inch) with any combination of redundant AC, 24VDC or 48VDC power supplies. They can also be mounted in a 2-module AC or 18 to 60VDC powered chassis, or in a 1-module AC/DC powered chassis.
