Omnitron Systems OmniConverter FPoE/SL 2x PoE 2x SFP US AC Powered Wide Temp
The OmniConverter FPoE/SL is a multi-port media converter that converts 10/100BASE-T UTP to 100BASE-FX fiber and support Power-over-Ethernet (PoE). Classified as Power Sourcing Equipment (PSE), OmniConverter FPoE/SL can provide power to one or two Powered Devices (PDs) using standard UTP cables that carry the Ethernet data. The OmniConverter functions as a PoE mini-switch, and supports a variety of port configurations, including single or dual UTP and SFP ports.
The OmniConverter media converters can power PDs such as VoIP phones, wireless access points, network cameras, building access and automation equipment. They are especially useful at powering PDs in hard-to-reach locations with limited access to AC power outlets (ceilings, closets, etc.). The cost of bringing electrical power to each device is eliminated by powering the equipment through the UTP cable.
- Supports IEEE 802.3af PoE on one or two RJ-45 copper ports
- Supports 100BASE-FX fixed-fiber and 100BASE-FX SFP transceivers
- Redundant protected fiber link option (using dual SFP transceivers)
- Configurable PoE power reset
- Available in AC and DC models
- Integrated wall mount brackets
- Commercial (0 to 50"C), wide (-40 to 60"C) and extended (-40 to 75"C) operating temperature ranges
- Lifetime Warranty and free 24/7 Technical Support
- Configurable PoE power reset
- Available in AC and DC models
- Compatible with legacy pre-IEEE standard powered devices
- Redundant protected fiber link option (using dual SFP transceivers)
- Supports 100BASE-X fixed-fiber and 100BASE-X SFP transceivers
- The FPoE+/S supports IEEE 802.3at PoE+ on one or two RJ-45 copper ports, and up to 10,240 byte frames
- The FPoE/S supports IEEE 802.3af PoE on one or two RJ-45 copper ports, and up to 10,240 byte frames
- The FPoE/SL supports IEEE 802.3af PoE on one or two RJ-45 copper ports, and up to 2,000 byte frames
- Power over Ethernet injector/source
- Extended operating temperature range of -40 to 75C
Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: WEEE
Country Of Origin: United States
Product Series: FPoE/SL
Brand Name: Omnitron Systems
Form Factor: Wall Mountable
Manufacturer: Omnitron Systems
Product Model: 9359-1-x
Product Name: OmniConverter FPoE/SL 2x PoE 2x SFP US AC Powered Wide Temp
Product Line: OmniConverter
Manufacturer Part Number: 9359-1-21Z
Manufacturer Website Address: http://www.omnitron-systems.com
Package Contents:
- OmniConverter FPoE/SL 2x PoE 2x SFP US AC Powered Wide Temp
- US Power Supply - 100-240Volt / 50-60Hz
- US AC Power Cord
- User Manual
Limited Warranty: Lifetime
Weight (Approximate): 1 lb
