Minuteman Endurance END1500RT2U-LNC Online UPS
The Minuteman Endurance END1500RT2U-LNC is a true sine wave online UPS engineered for mission-critical IT infrastructure, data centers, and sensitive electronics requiring continuous, uninterrupted power protection. This 1500VA/1350W lithium battery UPS delivers enterprise-grade reliability with dual installation flexibility—rack or tower format—making it ideal for server rooms, network closets, and distributed IT environments where downtime is not an option. Built on high-density, double-conversion technology, the END1500RT2U-LNC ensures your critical systems stay online with clean, regulated power during outages, surges, and utility fluctuations.
Key Features
- True sine wave output for sensitive equipment protection
- Online double-conversion UPS technology for continuous power conditioning
- 1500VA/1350W capacity at 120V with 0.9 power factor
- High-density lithium battery for extended runtime and reliability
- Flexible rack or tower installation formats
- Endurance Series design for long-term operational performance
- Ideal for servers, networking equipment, and critical IT systems
Technical Specifications
| Specification |
Details |
| Manufacturer |
Minuteman UPS |
| Model |
END1500RT2U-LNC |
| Series |
Endurance Series |
| UPS Type |
Online True Sine Wave |
| Battery Technology |
Lithium |
| Power Rating |
1500VA / 1350W |
| Input Voltage |
120V |
| Power Factor |
0.9 |
| Installation Format |
Rack Mount or Tower |
| Output Waveform |
True Sine Wave |
| Technology |
Double-Conversion |
Frequently Asked Questions
What is a true sine wave online UPS and why does it matter?
A true sine wave online UPS continuously converts incoming AC power through double-conversion technology, delivering perfectly clean, regulated output that matches utility-grade power. Unlike simulated sine wave units, true sine wave systems protect sensitive electronics—servers, storage arrays, and networking gear—from harmonic distortion and voltage anomalies, ensuring zero downtime and equipment longevity.
How long will the lithium battery provide backup power?
The 1500VA/1350W lithium battery in the END1500RT2U-LNC provides extended runtime compared to traditional lead-acid alternatives. Actual backup duration depends on connected load; at 50% capacity, expect 10-15 minutes of runtime, sufficient for graceful system shutdown or failover to alternative power sources. Lithium chemistry also delivers superior cycle life and reliability over the UPS lifespan.
Can I install the END1500RT2U-LNC in both rack and tower configurations?
Yes. The Endurance Series design supports flexible deployment—install as a 2U rack-mount unit in standard 19-inch server racks or position as a tower on floors or shelves. This versatility makes it ideal for diverse IT environments, from compact network closets to distributed edge computing installations.
Is the END1500RT2U-LNC suitable for data center and server room applications?
Absolutely. With 1500VA capacity, true sine wave output, and lithium battery reliability, this online UPS is engineered for mission-critical infrastructure. The double-conversion architecture ensures continuous power conditioning, protecting servers, switches, and storage systems from utility instability while maintaining uptime SLAs.
