Easily distribute a single Ultra-High-Definition (UHD) signal to multiple displays.
The Manhattan Mini DisplayPort to 2-Port HDMI Splitter Hub with Multi-Stream Transport (MST) streams a 4K DisplayPort signal from a single UHD source to up to two UHD HDMI displays.
Flexible Solution for Many A/V Applications
Ideal for trade shows, classrooms, video conferencing, presentations and retail applications, the Manhattan Mini DisplayPort to 2-Port HDMI Splitter Hub with MST features a built-in booster for added signal strength. It's a great choice for splitting and distributing a synchronous signal, in either mirrored or extended modes, to multiple 4K HDMI displays. MST mode creates a video wall from two displays to give the user a more immersive experience when gaming, in a conference setting or in a home office.
Quality Construction and Easy Installation
Full compliance with DisplayPort, HDCP 2.2 and DVI 1.0 ensures that the Manhattan Mini DisplayPort to 2-Port HDMI Splitter Hub with MST can provide long service and reliable performance. Quickly connect HDMI cables (not included) and the included USB power cable, and this affordable, Ultra-High-Definition 4K DisplayPort/HDMI solution is complete - no software/hardware configuration or complicated settings required.
- Duplicates an Ultra-High-Definition (UHD) Mini DisplayPort (Mini DP) signal for up to two UHD HDMI displays
- 4K@30Hz resolution, full 3D video and Deep Color
- Supports compressed DTS Master Audio, as well as 7.1 surround sound audio up to 192 kHz
- Supports Mirror, Extended and Multi-Stream Transport (MST) modes to maximize work or gaming capabilities
- Mirror mode duplicates the computer screen onto two displays with resolutions up to 4K@30Hz
- Extended mode expands the desktop workspace to up to two additional screens with resolutions up to 4K@30Hz
- MST mode creates a video wall for a more immersive experience, using two screens - with resolutions up to 3840x2160 at 30 Hz - as one; requires a graphics card that supports video-wall function
- USB powered with Plug and Play installation; no special setup or remote required
- Integrated Mini DisplayPort cable
- Ideal for enhancing display capabilities or creating a video wall in locations such as schools, churches, conference rooms, trade shows and retail outlets; perfect for digital signage and AMD Eyefinity Technology in gaming
Product Type: Signal Splitter
Environmentally Friendly: Yes
Environmental Certification: RoHS 2
Product Material: Plastic
Brand Name: Manhattan
Manufacturer: Manhattan
Product Model: 152723
Product Name: Mini DisplayPort to 2-Port HDMI Splitter Hub with MST
Package Type: Retail
Manufacturer Part Number: 152723
Manufacturer Website Address: http://www.manhattan-products.com
Package Contents:
- Mini DisplayPort to 2-Port HDMI Splitter Hub with MST
- USB Power Cable
- Quick Instruction Guide
Limited Warranty: 3 Year
Weight (Approximate): 1.76 oz
