Microchip Gps/Galileo/Glonass Antenna 990-15202-100

Microchip GPS/Galileo/Glonass Antenna
The standard antenna used with the SyncServer S600/S650 and TimeProvider4100 is a high-gain (40 dB) GNSS antenna covering the GPS L1,Galileo E1, GLONASS L1, and SBAS (WAAS, EGNOS, QZSS and MSAS) frequency band (1575 MHz to 1606 MHz). The antenna has a three-stage low-noise amplifier, with a mid-section SAW with a tight pre-filter to protect against saturation by high- level sub-harmonics and L-Band signals, making it excellent for timing applications. An L-bracket for pole mounting and 3-foot BNC(m) to N(f) cable is also included.

• Delivers?enhanced performance at 1575 MHz to 1606 MHz frequency


• Dramatically enhance the performance of gps with this antenna


• Provides gain of up to 40 dB


• Mountable to poles for easy installation

Product Type: Antenna
Product Color: White
Diameter: 2.62"
Country Of Origin: United States
Brand Name: Microchip
Compatibility:

Microsemi Products:

• SyncServer S600
• SyncServer S650
• TimeProvider 4100 Series
