Taoglas Pantheon MA761 4in1 LTE/Wi-Fi MIMO Antenna, 3M CFD-200
MA761 Pantheon antenna is an omni-directional, heavy-duty, fully IP67 waterproof external M2M antenna for use in telematics, transportation and remote monitoring applications.
This unique antenna delivers powerful MIMO antenna technology for LTE and Wi-Fi 802.11n and emerging 802.11ac for next generation high bandwidth telematics systems.
New fleet management and video location technology allows for real-time video uplink and downlink. High efficiency high gain MIMO antennas are necessary to achieve the high signal to noise ratio and throughput required to solve these challenges.
We have packed 4 high efficiency and gain antennas in an extremely robust IP67 direct mount antenna package with good isolation (10dB+). The antenna has its own ground-plane and can radiate on any mounting environment like metal or plastic without affecting performance. The cables are low loss allowing for lengths of up to 10 meters (32 ' and 9.70 "), critical for buses, trains and other commercial transport applications.
Customized cables and connector version available.
- 2 x 4G/3G/2G MIMO Antenna (698~960MHz,1710~2170MHz,2300~2700MHz, 2900-3500MHz): MIMO1 antenna, MIMO2 antenna
- 2 x 2.4GHz/5GHz MIMO Antenna: MIMO1 antenna, MIMO2 antenna
- IP67 Waterproof
- High Efficiency / Peak Gain Outdoor Antenna
- RoHS Compliant
Product Type: Antenna
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Color: Black
Diameter: 5.64"
Country Of Origin: Taiwan
Product Series: MA761
Brand Name: Taoglas
Form Factor: Screw Mount
Manufacturer: Taoglas
Product Name: Pantheon MA761 4in1 LTE/Wi-Fi MIMO Antenna, 3M CFD-200
Product Line: Pantheon
Application/Usage: Outdoor
Manufacturer Part Number: MA761.B.BICG.003
Manufacturer Website Address: http://www.taoglas.com
Weight (Approximate): 2.56 lb
