Linear Nbt125-W Access Reader

Linear NBT125-W Access Reader

125 kHz reader for indoor & outdoor installations. Mullion and single gang mounts included (2N1).

Description

The NBT125-W supports all Linear 125 kHz cards & fobs, and supports most cards & fobs made by HID, AWID and Farpointe (HAF).

NBT125-W outputs reader-to-controller data in Wiegand format, making it compatible with a vast majority of existing access control panels.

2-N-1: Includes single-gang and mullion mounting hardware in the box.

IP67 rated for indoor and outdoor installations.

• Frequency: 125 kHz (contactless prox)


• Mounting: A single reader for metal door and windows frames, single-gang wall boxes, and flat surfaces.


• Dimensions (Mullion): 1.48" W x 4.74" H x 0.54" D (37.5 mm x 120 mm x 13.7 mm)


• Dimensions (Single-gang): 2.99" W x 4.74" H x 0.54" D (76.2 mm x 120 mm x 13.7 mm)


• Certifications: FCC, ICC, CE, UL Standard 2942, IP67


• Read Range: Up to 3 inches (76 mm)


• Cabling: 24 AWG minimum, multiconductor, stranded, with an overall foil shield


• Supported Data Output: Wiegand


• Operating Temperature: -40° F to 149° F (-40° C to +65° C)


• Audio Tone Beeper: Included standard

Product Type: Card Reader Access Device
Brand Name: Linear
Compatibility: 125 Proximity Credentials

ISO CARDS:

• HID Models:
• ISO125-H
• ISO125-HC
• AWID Models:
• ISO125-A
• ISO125-AC

• HID Models:
• CLM125-H
• CLM125-HC
• AWID Models:
• CLM125-A
• CLM125-AC

• HID Models:
• KFB125-H
• KFB125-HC
• AWID Models:
• KFB125-A
• KFB125-AC

• NBT125-W Access Reader
• Mullion and Single-Gang Mounts with Adapter Plate
• Installation Hardware
