Lenovo ThinkSystem DE4000H DAS/SAN Storage System
Lenovo ThinkSystem DE4000H is a scalable, hybrid entry-level storage system that is designed to provide performance, simplicity, capacity, security, and high availability for medium to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features. The ThinkSystem DE4000H is a perfect fit for a wide range of enterprise workloads, including big data and analytics, video surveillance, technical computing, backup and recovery, and other storage I/O-intensive applications.
ThinkSystem DE4000H models are available in a 2U rack form-factor with 24 small form-factor (2.5-inch SFF) drives (2U24 SFF), 12 large form-factor (3.5-inch LFF) drives (2U12 LFF), or a 4U rack form-factor with 60 LFF drives (4U60 LFF) and include two controllers, each with 8 GB or 32 GB memory for a system total of 16 GB or 64 GB. Host interface cards provide 12 Gb SAS, 10/25 Gb iSCSI, or 8/16/32 Gb FC connections.
The ThinkSystem DE4000H Storage Array scales up to 192 drives with the attachment of Lenovo ThinkSystem DE120S 2U12, DE240S 2U24 SFF, and DE600S 4U60 LFF Expansion Enclosures. It also offers flexible drive configurations with the choice of 2.5-inch (SFF) and 3.5-inch (LFF) form factors, 10 K rpm SAS and 7.2 K rpm NL SAS hard disk drives (HDDs), and SAS solid-state drives (SSDs).
- DAS/SAN Storage System offers maximum storage productivity with added dependability
- Holds up to 60 HDDs to let you expand limitlessly
- Through RAID levels (0, 1, 3, 5, 6, 10), RAID provides data reliability, fault tolerance and improves overall performance
- RAID technology - data reliability, fault tolerance and improved overall performance
- Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
Product Type: DAS/SAN Storage System
Additional Warranty Information: Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered.
Environmentally Friendly: Yes
Environmental Certification: EU RoHS
Product Series: DE
Rack Height: 4U
Brand Name: Lenovo
Form Factor: Rack-mountable
Manufacturer: Lenovo Group Limited
Product Model: DE4000H
Product Name: ThinkSystem DE4000H DAS/SAN Storage System
Product Line: ThinkSystem
Manufacturer Part Number: 7Y77A00AWW
Manufacturer Website Address: http://www.lenovo.com/us/en/
Package Contents:
- ThinkSystem DE4000H DAS/SAN Storage System
- Rack Mount Kit
- 2 m USB Cable (USB Type A to Micro-USB)
- Quick Installation Guide
- Electronic Publications Flyer
- 2 x Power Cables
Limited Warranty: 3 Year
Weight (Approximate): 238.25 lb
