Lenovo 00MM950. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Fiber. Maximum data transfer rate: 40000 Mbit/s. Product colour: Green
ConnectX-4 from Mellanox is a family of high-performance and low-latency Ethernet and InfiniBand adapters. The ConnectX-4 Lx EN adapters are available in 40 Gb and 25 Gb Ethernet speeds and the ConnectX-4 Virtual Protocol Interconnect (VPI) adapters support either InfiniBand or Ethernet.
These adapters address virtualized infrastructure challenges, delivering best-in-class performance to various demanding markets and applications. Providing true hardware-based I/O isolation with unmatched scalability and efficiency, achieving the most cost-effective and flexible solution for Web 2.0, Cloud, data analytics, database, and storage platforms.
The following figure shows the Mellanox ConnectX-4 2x100GbE/EDR IB QSFP28 VPI Adapter (the standard heat sink has been removed in this photo).
General Information
Manufacturer
Lenovo Group Limited
Manufacturer Part Number
00MM950
Manufacturer Website Address
http://www.lenovo.com/us/en/
Brand Name
Lenovo
Product Name
Mellanox ConnectX-4 Lx 1x40GbE QSFP28 Adapter
Product Type
40Gigabit Ethernet Card
UPC
889488417285
Miscellaneous
Package Contents
Mellanox ConnectX-4 Lx 1x40GbE QSFP28 Adapter
Additional Low-Profile (2U) Bracket
Quick Installation Guide
Documentation CD
Warranty Flyer
Important Notices Flyer
Environmentally Friendly
Yes
