Legrand DX³ Shunt Trip 110-415VAC 1M
The DX³ shunt trip is a specialized accessory designed for the Legrand DX³ circuit breaker range, engineered to provide reliable remote tripping capability across industrial and commercial electrical systems. Operating seamlessly across 110-415VAC voltage ranges, this 1-module device delivers precise electrical protection and control for demanding applications requiring automated circuit disconnection.
This shunt trip accessory integrates directly with DX³ breakers, enabling remote operation and emergency shutdown functionality. Ideal for facilities requiring centralized electrical management, the DX³ shunt trip ensures rapid response times and enhanced system safety in critical installations.
Key Features
- Operating voltage range: 110-415VAC for flexible system integration
- 1-module compact design for space-efficient DIN rail installation
- Direct compatibility with Legrand DX³ circuit breaker range
- Remote tripping capability for automated circuit control
- Industrial-grade construction for reliable performance
- Enables emergency shutdown and safety interlocking applications
Technical Specifications
| Specification |
Details |
| Manufacturer |
Strategic Sourcing / Legrand |
| Product Series |
DX³ |
| Part Number |
406278 |
| Device Type |
Shunt Trip Accessory |
| Operating Voltage |
110-415VAC |
| Module Count |
1M |
| Installation |
DIN Rail Mount |
| Application |
Circuit Breaker Remote Control |
Frequently Asked Questions
What is a shunt trip device used for?
A shunt trip is an electromagnetic accessory that enables remote or automatic tripping of circuit breakers. The DX³ shunt trip allows operators to disconnect power remotely, making it essential for emergency shutdown systems, safety interlocks, and centralized electrical management in industrial facilities.
Is the DX³ shunt trip compatible with my Legrand breaker?
Yes, this DX³ shunt trip accessory is specifically designed for the Legrand DX³ circuit breaker range. It integrates directly onto compatible DX³ breakers for seamless remote control functionality across 110-415VAC systems.
What voltage range does this shunt trip support?
The DX³ shunt trip operates across a wide 110-415VAC voltage range, making it suitable for single-phase and three-phase electrical systems in both industrial and commercial applications requiring flexible voltage compatibility.
How is the shunt trip installed?
The 1-module DX³ shunt trip mounts directly onto compatible Legrand DX³ breakers via DIN rail installation. No additional wiring modifications are required—simply attach the accessory to the breaker and connect the control circuit for immediate remote tripping capability.
