Allied Telesis Gigabit Layer 3 PoE++ Switch
The Allied Telesis x320-10GH Gigabit Layer 3 PoE++ switch offers an impressive set of features in a compact design. Flexible PoE capabilities support the high power devices found in today's smart buildings and business environments.
Overview
Allied Telesis x320-10GH is secure and reliable, with advanced power connectivity features - and provides great value to meet the needs of today's connected business, with the ability to provide up to 90 Watts of PoE power on all ports.
Flexible PoE
The x320-10GH supports commonly used PoE standards, providing the 15.4 Watts of PoE (802.3af), the 30 Watts of PoE+ (802.3at), and the 60 or 90 Watts of PoE++ (802.11bt).
Continuous PoE
Continuous PoE allows the x320-10GH to be restarted without affecting the supply of power to connected devices. Smart lighting, security cameras, and other PoE devices will continue to operate during a software upgrade on the switch.
Powerful Network Management
Meeting the increased management requirements of modern converged networks, Allied Telesis Autonomous Management Framework™ (AMF) automates many everyday tasks including configuration management. The complete network can be managed as a single virtual device with powerful centralized management features. Growing the network can be accomplished with plug-and-play simplicity, and network node recovery is fully zero-touch.
AMF secure mode increases network security with management traffic encryption, authorization, and monitoring. AMF Guestnode allows third party devices, such as IP phones and security cameras, to be part of an AMF network.
Network resiliency
Allied Telesis Ethernet Protection Switched Ring (EPSRing™), and the standards-based G.8032 Ethernet Ring Protection, ensure that distributed network segments have high-speed, resilient access to online resources and applications.
Secure
A secure network environment is guaranteed. The x320-10GH offers powerful control over network traffic types, secure management options, loop guard to protect against cabling mistakes, and tri-authentication for comprehensive access control.
The x320-10GH uses 802.1x portbased authentication, in partnership with standards-compliant dynamic VLAN assignment, to assess a user's adherence to network security policies and either grant access or offer solutions. Tri-authentication ensures the network is only accessed by designated users and devices. Secure access is also available for guests.
Security from malicious network attacks is provided by a comprehensive range of features such as DHCP snooping, STP root guard, BPDU protection, and access control lists. Each of these can be configured to perform a variety of actions upon detection of a suspected attack or malfunctions.
Environmentally friendly
The x320-10GH supports Energy Efficient Ethernet (EEE), automatically reducing the power consumed by the switch whenever there is no traffic on a port. This sophisticated feature can significantly reduce operating costs by reducing the power requirements of the switch and any associated cooling equipment.
The x320-10GH is fanless, providing silent operation, which makes it ideal for work area deployment.
- Features 8 networking ports to easily establish a local network or expand your existing one
- Cascade to other network devices through the uplink port to expand your local area network
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Can work as layer 3 routing for scalable network design
- Managed switch provides a reliable foundation for your network
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Rack mounting enables you to organize wires & secure cables for professional installation
Product Type: Layer 3 Switch
Compatible Rack Unit: 1U
Brand Name: Allied Telesis
Form Factor: Rack-mountable
Manufacturer: Allied Telesis, Inc
Product Model: x320-10GH
Product Name: Gigabit Layer 3 PoE++ Switch
Manufacturer Part Number: AT-X320-10GH
Manufacturer Website Address: http://www.alliedtelesis.com
Weight (Approximate): 3.53 lb
