Kramer VS-1616DN-EM 4K60 Modular Matrix Switcher Chassis
The VS-1616DN-EM is a professional-grade modular matrix switcher chassis designed for high-performance AV signal routing in enterprise, broadcast, and live event environments. This 4K@60Hz (4:2:0) digital matrix switcher scales from 2x2 to 16x16 configurations, making it ideal for control rooms, conference centers, and integrated AV systems requiring flexible signal management. Whether you're managing multiple video sources or complex audio-visual workflows, this multi-format digital switcher delivers reliable switching with optional redundancy and comprehensive monitoring capabilities.
Key Features
- Scalable 2x2 to 16x16 modular matrix switcher architecture with incremental expansion
- 4K@60Hz (4:2:0) resolution support for modern digital displays and projectors
- Multi-format digital switcher supporting diverse AV signal types
- Wide variety of input and output card options for flexible signal compatibility
- Optional dual redundant power supplies for mission-critical installations
- Integrated control module for centralized AV signal management
- Built-in test module for real-time input and output monitoring
- Professional-grade chassis design for rack-mount deployment
Technical Specifications
| Specification |
Details |
| Manufacturer |
KRAMER ELECTRONICS |
| Part Number |
28-70001430 |
| Model |
VS-1616DN-EM |
| Matrix Configuration |
2x2 to 16x16 (scalable in 2-input/2-output increments) |
| Video Resolution |
4K@60Hz (4:2:0) |
| Switcher Type |
Modular digital matrix switcher chassis |
| Signal Support |
Multi-format AV signals |
| Power Supply |
Optional dual redundant power supplies |
| Control |
Integrated control module with test module |
| Monitoring |
Real-time input/output testing and diagnostics |
Frequently Asked Questions
What is a modular matrix switcher chassis?
A modular matrix switcher chassis is a scalable AV routing platform that allows you to configure input and output cards based on your specific needs. The VS-1616DN-EM grows from 2x2 to 16x16, letting you start small and expand as your system requirements increase without replacing the entire chassis.
Does the VS-1616DN-EM support 4K resolution?
Yes, the VS-1616DN-EM is a 4K@60Hz (4:2:0) digital matrix switcher, making it compatible with modern 4K displays, projectors, and professional video equipment. This ensures future-proof signal routing for high-resolution AV environments.
Can I add redundant power to this matrix switcher?
Yes, the VS-1616DN-EM supports optional dual redundant power supplies, providing failover protection for mission-critical AV installations. This feature ensures continuous operation even if one power supply fails.
What monitoring capabilities does this AV switcher include?
The integrated test module allows real-time monitoring and testing of any input or output in the matrix, enabling proactive diagnostics and troubleshooting without interrupting your AV signal routing.
