KP Performance KP-3SX4-90-V2 5G MIMO Sector Panel Antenna
The KP-3SX4-90-V2 is a professional-grade 5G MIMO sector panel antenna engineered for high-performance base station deployments across the 3300–4200 MHz band. This 4-port MIMO antenna delivers 17 dBi directional gain with a 90-degree sector beamwidth, making it ideal for point-to-multipoint wireless networks in 5G and CBRS applications. With ±45° slant polarization and N-Type female connectors, it provides superior coverage efficiency and signal quality for carriers and network operators requiring reliable, directional antenna solutions.
Key Features
- 4-Port MIMO Configuration — Simultaneous multi-stream transmission for enhanced capacity
- 17 dBi Directional Gain — Optimized for extended coverage range in sector deployments
- 90-Degree Sector Beamwidth — Precise directional coverage pattern for base station applications
- ±45° Slant Polarization — Dual-polarization support for improved signal reliability
- 3300–4200 MHz Operating Band — Full coverage across mid-band 5G and CBRS spectrum
- N-Type Female Connectors — Industry-standard RF connections for reliable integration
- Base Station Optimized — Purpose-built for carrier-grade wireless infrastructure
Technical Specifications
| Specification |
Value |
| Manufacturer |
STRATEGIC SOURCING |
| Part Number |
KP-3SX4-90-V2 |
| Antenna Type |
4-Port MIMO Sector Panel |
| Frequency Band |
3300–4200 MHz |
| Gain |
17 dBi |
| Sector Beamwidth |
90 Degrees |
| Polarization |
±45° Slant (Dual) |
| Connector Type |
N-Type Female |
| Application |
5G Base Station, CBRS, Point-to-Multipoint |
Frequently Asked Questions
What is a 4-port MIMO sector panel antenna used for?
A 4-port MIMO sector panel antenna is designed for base station deployments where multiple simultaneous data streams improve network capacity and coverage. The sector configuration provides directional coverage across a 90-degree area, making it ideal for 5G and CBRS networks requiring high-performance point-to-multipoint connectivity.
What does 17 dBi gain mean for 5G antenna performance?
The 17 dBi directional gain amplifies the antenna's effective radiated power, extending coverage range and improving signal strength in the target sector. This makes the KP-3SX4-90-V2 suitable for base station applications where extended range and reliable signal delivery are critical.
Is the KP-3SX4-90-V2 compatible with standard base station equipment?
Yes, the antenna features industry-standard N-Type female connectors, ensuring compatibility with most carrier-grade base station equipment and RF distribution systems operating in the 3300–4200 MHz band.
What is ±45° slant polarization and why does it matter?
±45° slant polarization provides dual-polarization support, allowing the antenna to transmit and receive signals at two orthogonal angles simultaneously. This improves signal reliability, reduces interference, and enhances overall network performance in 5G deployments.
