Description
DESCRIPTION Kingston's KSM26RS4/16HDI is a 2G x 72-bit (16GB) DDR4-2666 CL19 SDRAM (Synchronous DRAM) registered w/ parity, 1Rx4, ECC, memory module, based on eighteen 2G x 4-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-2666 timing of 19-19-19 at 1.2V. Each 288-pin DIMM uses gold contact fingers. FEATURES • Power Supply: VDD = 1.2V • VDDQ = 1.2V • VPP = 2.5V • VDDSPD = 2.41V to 2.75V • Functionality and operations comply with the DDR4 SDRAM datasheet • 16 internal banks • Bank Grouping is applied, and CAS to CAS latency (tCCD_L, tCCD_S) for the banks in the same or different bank group accesses are available • Data transfer rates: PC4-2666, PC4-2400, PC4-2133, PC4-1866, PC4-1600 • Bi-Directional Differential Data Strobe • 8 bit pre-fetch • Burst Length (BL) switch on-the-fly BL8 or BC4 (Burst Chop) • Supports ECC error correction and detection • On-Die Termination (ODT) • Temperature sensor with integrated SPD • This product is in compliance with the RoHS directive. • Per DRAM Addressability is supported • Internal Vref DQ level generation is available • Write CRC is supported at all speed grades • CA parity (Command/Address Parity) mode is supported Product Type: RAM Module CAS Latency: CL19 Device Supported: Server Error Checking: ECC/Parity Number of Pins: 288-pin Signal Processing: Registered Product Type: RAM Module CAS Latency: CL19 Device Supported: Server Error Checking: ECC/Parity Manufacturer Part Number: KSM26RS4/16HDI Number of Pins: 288-pin Signal Processing: Registered Limited Warranty: Lifetime Form Factor: DIMM Memory Speed: 2666 MHz Form Factor: DIMM Length: 5.3 Manufacturer: Kingston Technology Company Memory Speed: 2666 MHz Product Name: 16GB DDR4 SDRAM Memory Module Memory Size: 16 GB Brand Name: Kingston Memory Size: 16 GB Brand Name: Kingston Memory Technology: DDR4 SDRAM Memory Technology: DDR4 SDRAM Memory Standard: DDR4-2666/PC4-21300 Country of Origin: Taiwan Memory Standard: DDR4-2666/PC4-21300 Width: 1.2 Memory Voltage: 1.20 V Environmentally Friendly: Yes Environmental Certification: Taiwan RoHS Environmental Certification: PFOS Environmental Certification: ECHA Environmental Certification: REACH Environmental Certification: RoHS 2 Environmental Certification: WEEE Environmental Certification: RoHS Memory Voltage: 1.20 V
General Information
Manufacturer
Kingston Technology Company
Manufacturer Part Number
KSM26RS4/16HDI
Manufacturer Website Address
http://www.kingston.com
Brand Name
Kingston
Product Name
16GB DDR4 SDRAM Memory Module
Product Type
RAM Module
UPC
0740617308181
Width
1.2"
Environmentally Friendly
Yes
Environmental Certification
Hazard Assessment of Perfluorooctane Sulfonate (PFOS)
Warranty
Limited Warranty
Lifetime
Roll over image to zoom inClick on image to zoom
/
