Technical Specifications|
| Product Type: Mounting Bracket |
| Product Color: White |
| Product Material: Metal |
| Brand Name: JBL |
| Compatibility: JB Pro Speakers: - CBT-50LA-1
- 100LA-1
- 200LA-1, 70J-1
- 70J-1+70JE-1
- 1000
- 1000+1000E
|
| Manufacturer: Harman International Industries, Inc |
| Product Name: Bent-Metal Adapter Plates |
| Manufacturer Part Number: MTC-CBT-SUS3 |
| Manufacturer Website Address: http://www.harman.com |
| Packaged Quantity: 2 |
Package Contents: - Bent-Metal Adapter Plates
- Hardware
|
JBL Mounting Bracket for Speaker - White
Suspension Adapter Plates for ALL CBT Models
Suspension Adapter Plates for ALL CBT Models. Bent-metal adapter plates that provide convenient clip points for suspending CBT speakers via aircraft cable and other methods. Includes 2 pcs, for top & bottom mounting. Provides 3 clip points each -- center and two sides. Drilled with three speaker spacing/bolt patterns to fit: CBT-50LA-1, 100LA-1, 200LA-1, 70J-1, 70J-1+70JE-1 array, 1000, 1000+1000E array. The MTC-CBT-SUS3 suspension bracket can be mounted to the top and bottom of the CBT 1000 and CBT 1000 + 1000E System if desired. Special hardware in included in the kit that is designed for use with this bracket mounting place (M8 x 40 mm x8) and it is the only hardware that can be used for this purpose.
