InVid Tech VN2A-128: 128 Channel NVR for Enterprise Surveillance
The InVid Tech VN2A-128 is a 128 channel network video recorder engineered for large-scale surveillance deployments requiring high-capacity recording and multi-display capabilities. This professional-grade 128 Ch NVR supports up to 512 Mbps incoming bandwidth, making it ideal for security integrators, enterprise facilities, and government installations managing extensive camera networks. With 4K output support, sixteen hard drive bays for massive storage, and four NIC cards for redundant connectivity, the VN2A-128 delivers enterprise-level reliability and scalability for mission-critical surveillance operations.
Key Features
- 128 channel network video recorder with simultaneous recording of all channels
- 512 Mbps incoming bandwidth for high-capacity surveillance deployments
- 16 hard drive bays for extended storage and retention periods
- Four NIC cards for network redundancy and failover protection
- 4K output resolution for crystal-clear video display and analysis
- Display up to 64 channels simultaneously on primary display
- Support for 128 channel viewing with VIS-HDMI4 4-port expansion card
- Cloud upgrade option for remote access and scalable storage
- Professional-grade NVR architecture for 24/7 continuous recording
Technical Specifications
| Specification |
Details |
| Manufacturer |
INNOVATIVE VIDEO TECHNOLOGY |
| Model |
VN2A-128 |
| Recording Channels |
128 channels |
| Bandwidth Support |
512 Mbps incoming |
| Hard Drive Bays |
16 bays |
| Network Interface Cards |
4 NIC cards |
| Video Output |
4K resolution |
| Simultaneous Display |
64 channels (expandable to 128 with VIS-HDMI4) |
| Expansion Options |
VIS-HDMI4 4-port expansion card, cloud upgrade |
| Recording Type |
Continuous 24/7 operation |
Frequently Asked Questions
What is the maximum number of cameras supported by the VN2A-128 NVR?
The InVid Tech VN2A-128 supports up to 128 IP cameras simultaneously, with the ability to record all channels continuously. You can display 64 channels at once on the primary monitor, and expand to view all 128 channels by adding the VIS-HDMI4 4-port expansion card for multi-display setups.
How much storage capacity does this 128 channel NVR provide?
With 16 hard drive bays, the VN2A-128 offers substantial storage flexibility. The total capacity depends on the hard drives installed, but this configuration supports extended retention periods for large-scale surveillance operations, making it suitable for enterprises requiring long-term video archival.
Does the 512 Mbps NVR support redundancy and failover?
Yes, the VN2A-128 features four NIC cards built-in, providing network redundancy and failover capabilities. This ensures continuous recording and monitoring even if one network connection fails, critical for mission-critical surveillance deployments.
Can I access the 128 channel NVR remotely?
The VN2A-128 includes a cloud upgrade option that enables remote access to your surveillance system. This allows authorized users to view live feeds and recorded video from anywhere, providing flexibility for distributed management of large surveillance networks.
