InVid Tech PN1B-8X8NH: 8-Channel NVR with 8 Plug & Play PoE Ports
The InVid Tech PN1B-8X8NH 8-channel NVR is a professional-grade network video recorder designed for small to medium security installations requiring reliable, scalable surveillance. This 8-channel NVR features 8 integrated plug and play PoE ports, eliminating the need for external power injectors and simplifying deployment. With 80 Mbps bit rate input capacity and support for up to 8 MP resolution recording, it delivers crystal-clear video capture for comprehensive site monitoring. The unit includes smart analytic support for intelligent video search and review, making incident investigation faster and more efficient. Perfect for businesses, retail locations, and facilities managers who need professional surveillance without complex setup.
Key Features
- 8-channel network video recorder with simultaneous 8-channel playback capability
- 8 integrated plug and play PoE ports for simplified camera connectivity
- 80 Mbps bit rate input for high-bandwidth video streams
- Supports up to 8 MP resolution recording for detailed video capture
- Smart analytic support for efficient video search and intelligent review
- Single hard drive bay accommodates up to 18 TB storage capacity
- 4K HDMI main monitor output for premium video display
- VGA output up to 1080p for secondary monitor connectivity
- Professional-grade network video recorder for 24/7 surveillance operations
Technical Specifications
| Specification |
Details |
| Manufacturer |
INNOVATIVE VIDEO TECHNOLOGY |
| Model Number |
PN1B-8X8NH |
| Channels |
8-channel NVR |
| PoE Ports |
8 plug and play ports |
| Bit Rate Input |
80 Mbps |
| Maximum Resolution |
8 MP |
| Simultaneous Playback |
8-channel |
| Storage |
1 hard drive bay (up to 18 TB) |
| Video Output - Primary |
4K HDMI |
| Video Output - Secondary |
VGA (up to 1080p) |
| Analytics |
Smart analytic support |
Frequently Asked Questions
What is an 8-channel NVR and how does it work?
An 8-channel NVR (network video recorder) is a surveillance system that records video from up to 8 IP cameras simultaneously. The InVid Tech PN1B-8X8NH connects cameras via its 8 plug and play PoE ports, which provide both power and data transmission over a single network cable, simplifying installation and reducing equipment costs.
Can I use this 8-channel NVR with existing cameras?
Yes, the PN1B-8X8NH supports up to 8 MP resolution recording and is compatible with standard IP cameras. The 8 integrated PoE ports provide plug and play connectivity, making it easy to integrate with most modern network cameras without additional power supplies or complex configuration.
What storage capacity does this network video recorder support?
The 8-channel NVR includes a single hard drive bay that accommodates drives up to 18 TB, providing substantial storage for extended video retention. The 80 Mbps bit rate input ensures efficient recording of multiple camera streams simultaneously.
Does the PN1B-8X8NH support 4K video output?
Yes, the InVid Tech 8-channel NVR features a 4K HDMI main monitor output for premium video display, plus a VGA output up to 1080p for secondary monitor connectivity, giving you flexible display options for surveillance monitoring.
