16 Channel NVR with 12TB Storage & 4K Monitoring
The InVid Tech PN1A-16X16-2NH/12TB is a professional-grade 16 channel NVR designed for seamless IP camera integration and high-performance surveillance. Built with 16 plug & play PoE ports, this network video recorder eliminates complex wiring while delivering enterprise-level recording capabilities. Perfect for security integrators, facility managers, and organizations requiring scalable surveillance infrastructure, this 16 channel NVR combines ease of deployment with powerful analytics and 4K monitoring output.
Record up to 8 megapixel resolution across all 16 channels simultaneously with a 96 Mbps bit rate input, ensuring crystal-clear footage for forensic analysis. The dual 2TB hard drive bays provide 12TB total storage capacity, while 16-channel simultaneous playback enables rapid incident review. 4K HDMI output delivers stunning visual clarity on modern displays.
Key Features
- 16 plug & play PoE ports for simplified IP camera deployment
- Supports up to 8 megapixel resolution recording across all channels
- 96 Mbps bit rate input for high-bandwidth surveillance streams
- Dual HD bays with 12TB total storage capacity
- 16-channel simultaneous playback for efficient incident investigation
- 4K HDMI output for premium monitoring displays
- Smart analytic functions for intelligent video analysis
- Enterprise-grade network video recorder architecture
Technical Specifications
| Specification |
Details |
| Manufacturer |
INNOVATIVE VIDEO TECHNOLOGY |
| Part Number |
PN1A-16X16-2NH/12TB |
| Recording Channels |
16 channels |
| PoE Ports |
16 plug & play ports |
| Maximum Resolution |
8 megapixel |
| Bit Rate Input |
96 Mbps |
| Storage Capacity |
12TB (2 HD bays) |
| Simultaneous Playback |
16 channels |
| Video Output |
4K HDMI |
| Analytics |
Smart analytic functions included |
Frequently Asked Questions
What is a 16 channel NVR and how does it work?
A 16 channel NVR (Network Video Recorder) is a surveillance device that records video streams from up to 16 IP cameras simultaneously. This network video recorder connects to cameras via Ethernet, processes video data, stores footage on internal hard drives, and enables playback and live monitoring through connected displays or remote interfaces.
Can I use plug and play PoE ports with any IP camera?
The 16 plug & play PoE ports on this NVR are designed for standard PoE IP cameras. Most modern surveillance cameras support PoE (Power over Ethernet), allowing single-cable connections that deliver both power and data, simplifying installation and reducing infrastructure costs.
How much video storage does 12TB provide?
Storage duration depends on resolution, frame rate, and compression settings. At 8 megapixel resolution across 16 channels, 12TB typically provides 7-14 days of continuous recording. The dual HD bays allow for easy expansion or replacement to extend retention periods as needed.
What are the benefits of 4K HDMI output on a surveillance NVR?
4K HDMI output delivers ultra-high-definition monitoring on compatible displays, providing superior image clarity for detailed forensic analysis, facial recognition, and license plate identification compared to standard HD outputs.
