The InVid Tech PD2B-16N is a 16 channel universal port DVR engineered for security professionals who demand flexibility and scalability. This TVI/AHD/CVI/Analog/IP compatible recorder supports up to 8 MP resolution across coax and IP inputs, making it ideal for mixed-camera environments. With 8 bonus IP channels for a maximum of 24 total IP cameras, expandable dual hard drive bays, and universal port technology, the PD2B-16N delivers enterprise-grade recording in a compact form factor.
Key Features
- 16 channel universal port recording with TVI/AHD/CVI/Analog/IP support
- Up to 8 MP resolution on coax and IP inputs
- 8 bonus IP channels for maximum 24 IP camera inputs
- Dual hard drive bays for expandable storage capacity
- Mixed-format compatibility eliminates camera standardization requirements
- Scalable architecture supports growing surveillance deployments
- Universal port design simplifies installation and reduces cabling complexity
Technical Specifications
| Specification |
Details |
| Manufacturer |
INNOVATIVE VIDEO TECHNOLOGY |
| Model |
PD2B-16N |
| Part Number |
PD2B-16N/8TB |
| Channels |
16 TVI/AHD/CVI/Analog + 8 Bonus IP (24 max IP) |
| Maximum Resolution |
8 MP |
| Input Types |
Coax (TVI/AHD/CVI/Analog), IP |
| Storage Bays |
2 Hard Drive Bays |
| Storage Capacity |
Expandable (8TB standard) |
Frequently Asked Questions
What is a universal port DVR and how does it benefit my security system?
A universal port DVR like the PD2B-16N accepts multiple camera formats (TVI, AHD, CVI, Analog, and IP) on the same device, eliminating the need for separate recorders. This reduces equipment costs, simplifies installation, and allows you to mix camera types within a single system for maximum flexibility.
Can I use the PD2B-16N with IP cameras only?
Yes. The 16 channel DVR includes 8 bonus IP channels, supporting up to 24 total IP camera inputs. This makes it an excellent choice for IP-based surveillance deployments or hybrid systems combining coax and IP cameras.
How much storage does the PD2B-16N provide?
The PD2B-16N features dual hard drive bays for expandable storage. The standard configuration includes 8TB capacity, with the ability to add additional drives for extended retention periods based on your recording resolution and frame rate requirements.
What resolution does this 16 channel recorder support?
The PD2B-16N supports up to 8 MP resolution on both coax and IP inputs, delivering high-definition video clarity for detailed surveillance footage and forensic analysis.
