Intel P5600 Mainstream - SSD - 1.6 TB - hot-swap - 2.5 - U.2 PCIe 4.0 x4 (NVMe) - for ThinkAgile MX3330-F Appliance;

Intel P5600 Mainstream - SSD - 1.6 TB - hot-swap - 2.5 - U.2 PCIe 4.0 x4 (NVMe) - for ThinkAgile MX3330-F Appliance; MX3330-H Appliance; MX3331-F Certified Node"

• PCIe 4.0 connection for each NVMe drive
• Intel 96 layer TLC 3D NAND Flash memory
• Ultra-low I/O latency
• Suitable for mixed read-write workloads
• Variable sector size and end-to-end data-path protection
• Enhanced power-loss data protection
• Thermal throttling and monitoring
• SMART health reporting

The Intel SSD D7-P5600 Series Mainstream NVMe SSDs are advanced data center SSDs optimized for mixed read-write performance, endurance, and strong data protection for Lenovo servers. With a PCIe 4.0 x4 interface, they are designed for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.
The Intel P5600 SSDs are based on Intel-developed controller, firmware, and 96-layer TLC Intel 3D NAND technology. Rigorous qualification and compatibility testing by Lenovo ensures a highly reliable SSD.
Non-Volatile Memory Express (NVMe) is PCIe high performance SSD technology that provides high I/O throughput and low latency. NVMe interfaces remove SAS/SATA bottlenecks and unleash all of the capabilities of contemporary NAND flash memory.
Each NVMe PCI SSD has direct PCIe x4 connection, which provides at significantly greater bandwidth and lower latency than SATA/SAS-based SSD solutions. NVMe drives are also optimized for heavy multi-threaded workloads by using internal parallelism and many other improvements, such as enlarged I/O queues. With a PCIe 4.0 host interface, the P5600 drives offer significant increase in maximum throughputs supported. Sequential writes also increase.

• Enhanced durability
  Built to withstand the demands of any environment, the P5600 Mainstream SSD features shock acceleration operating at 1000 g and vibration acceleration operating at 2.17 g, ensuring data integrity under high stress conditions.
• High-speed performance
  With an internal data rate of up to 3.5 GBps for reading and 1.7 GBps for writing, coupled with 400000 IOPS for 4KB random reads and 118000 IOPS for 4KB random writes, this SSD delivers swift and reliable performance for demanding applications.
• Advanced thermal management
  The P5600 Mainstream is equipped with thermal monitoring and throttling capabilities, alongside enhanced power loss data protection, to maintain optimal performance and data safety during intense operations.
• Substantial storage capacity
  Offering a generous 1.6 TB capacity and built with 96-layer 3D NAND technology, this SSD provides ample space for data storage and management, making it an ideal solution for high-capacity requirements.
