✅⚠️Availability Check: This item may have limited stock. Reach out to confirm before purchasing: Chat or email [email protected]
-
Mfr Part Number: BL631.FF300TB3F
-
Case Type: 11.5L S.F.F Slim Chassis(Ultra Small Form Factor)
-
Color: Black
-
M/B Type: Micro-ATX, Mini-ITX
-
Drive Bays: 5
-
External Bay: 5.25" x 1, 3.5" x 1
-
Internal Bay: 3.5" x 2, 2.5" x 1
-
Expansion Slots: 4x Low Profile Slots
-
Front I/O Panel: 2x USB 3.0 Ports, 2x USB 2.0 Ports, HD Audio
-
Power Supply: Standard TFX 12V Form Factor
-
Compatibility :
- Maximum Graphics Card Length / Width: 195 mm / 82 mm
- Maximum CPU Cooler Height: 72 mm
-
Certifications: Meets RoHS, CE and FCC Class B Requirements
-
Security : Padlock Loop / Kensington Slot
-
Optional :
- 80mm System Fan
- Removable Air Filter
- IEEE 1394
- Chassis Intrusion Switch
- Screwless ODD/FDD/HDD Bays Clips
- Screwless Expansion Slots Clip
- Screwless Side Cover Clips
- USB 2.0 x 2
- 3.5 to 2.5 HDD/SSD Bracket
- Key Lock Side Panel
-
Product Dimensions (H x W x D)with Front Panel : 330 x 96 x 416 mm(13 x 3.8 x 16.1) , 346 x 187 x 416 mm(with Foot Stand)
-
Product Dimensions(H x W x D)w/o Front Panel : 330 x 96 x 365 mm (11.5L)13" x 3.8" x 14.4"
-
Packing Dimensions(H x W x D): 478 x 400 x 153 mm(18.8 x 15.7 x 6)
General Information
| Manufacturer |
In Win Development, Inc |
| Manufacturer Part Number |
BL631.FF300TB3F |
| Manufacturer Website Address |
http://www.in-win.com.tw |
| Brand Name |
In Win |
| Product Name |
Computer Case |
| Product Type |
Computer Case |
| UPC |
827955030148 |
| Total Number of USB Ports | 4 |
|---|
| Product Color | Black |
|---|
| Height | 13.6" |
|---|
| Width | 7.4" |
|---|
| Depth | 16.4" |
|---|
| Environmentally Friendly | Yes |
|---|
Warranty
| Limited Warranty | 3 Year |
|---|
