Hikvision Digital Technology Ds-M5504Hni/Gw/Wi Digital Video Recorder (Dvr) Black

IP video 4ch, Audio in 4ch, 25/30fps, GPS, 3G, WLAN, 1.6kg

Hikvision Digital Technology DS-M5504HNI/GW/WI. Product colour: Black, Video compression formats: H.264, Compatible memory cards: SD. Video input channels: 4 channels. Ethernet interface type: Fast Ethernet. HDD interface: Serial ATA, Maximum HDD capacity: 1000 GB, HDD size: 2.5". Power consumption (standby): 0.5 W, Power consumption (max): 20 W

Features and Functions

- User-friendly GUI providing easy and flexible operations;
- Pluggable 4G (FDD-LTE), 3G (WCDMA) and Wi-Fi module providing flexible data transmission solutions;
- Pluggable GPS (Global Positioning System) module precisely positioning the vehicle via the satellite and recording the location information in the video stream;
- IP camera connection with Hikvision private protocol and ONVIF protocol supported;
- 4 independent network interfaces connectable to 4 IP cameras; each channel supports up to 1080P resolution with
- H.264 encoding technology;
- Two 2.5-inch HDDs/SSDs and one SD card pluggable, adopting hard disk vibration damping technology;
- Backup recording on SD card when the HDDs/SSDs are broken;
- Information collection interfaces collect driving information such as left/right turn, braking, rolling back, etc.;
- Left/right mirror type of the image configurable;
- Software-based firewall supported;
- Support accessing via WEB browser;
- Wide-range power input (9 to 32 VDC);
- Ignition startup and delay (0 h to 6 h) shutdown;
- Power-off protection prevents key data from loss;
- Standard 1DIN dimensions;
- Aluminum die-cast chassis of good heat dissipation performance with no fan design which well adapts to working environment;
- Hard disk box with USB interface supports intelligent temperature control and data export;
- Specialized aviation plugs ensure signal stability.
