HighPoint SSD7749E PCIe 4.0 x16 NVMe RAID Controller
The SSD7749E is a PCIe 4.0 x16 NVMe RAID controller purpose-built for industrial and edge server environments demanding compact, high-density storage with enterprise-class reliability. This 8-channel E1.S NVMe RAID AIC delivers up to 28,000MB/s throughput, hosting eight 9.5mm E1.S SSDs in a single PCIe Gen4 x16 slot. Ideal for data centers, edge computing nodes, and mission-critical applications requiring 24/7 uptime and maximum storage density in minimal physical space.
Key Features
- PCIe 4.0 x16 interface with full bandwidth support
- 8x E1.S NVMe SSD ports for high-density storage
- Up to 28,000MB/s sequential throughput
- Enterprise-grade RAID controller with 24/7 reliability
- Compact form factor fits standard PCIe x16 slots
- Industrial-grade design for edge server applications
- Hot-swap capable E1.S SSD support
- Advanced thermal management for sustained performance
Technical Specifications
| Specification |
Details |
| Manufacturer |
HighPoint Technologies |
| Model Number |
SSD7749E |
| Interface |
PCIe 4.0 x16 |
| NVMe Ports |
8x E1.S (9.5mm) |
| Max Throughput |
28,000MB/s |
| Form Factor |
AIC (Add-In Card) |
| Supported SSDs |
E1.S NVMe drives |
| Operating Environment |
Industrial & Edge Server |
| Reliability Rating |
Enterprise 24/7 |
Frequently Asked Questions
What is a PCIe 4.0 x16 NVMe RAID controller used for?
A PCIe 4.0 x16 NVMe RAID controller like the SSD7749E consolidates multiple high-speed NVMe drives into a single storage solution, providing RAID protection, increased capacity, and improved performance for edge servers, data centers, and industrial applications requiring reliable, high-density storage.
How many E1.S SSDs can the SSD7749E support?
The SSD7749E features 8x E1.S NVMe ports, allowing you to install up to eight 9.5mm E1.S SSDs for maximum storage density and redundancy options through RAID configurations.
What throughput speeds does this NVMe RAID AIC achieve?
The SSD7749E delivers up to 28,000MB/s sequential throughput, leveraging the full bandwidth of PCIe Gen4 x16 for ultra-fast data transfer in demanding industrial and edge computing environments.
Is the SSD7749E suitable for edge server applications?
Yes, the SSD7749E is specifically designed for edge server and industrial applications, featuring enterprise-class 24/7 reliability, compact integration into standard PCIe slots, and robust thermal management for mission-critical deployments.
