HighPoint SSD7580C PCIe 4.0 x16 NVMe RAID Adapter
The SSD7580C is a high-performance PCIe 4.0 x16 NVMe RAID adapter engineered for demanding workstation and server environments requiring maximum storage density and speed. This 8-channel U.2/U.3 host controller delivers up to 28GB/s transfer performance, making it ideal for data-intensive applications, virtualization, and enterprise storage solutions. Whether you're building a high-capacity storage server or upgrading your workstation with bootable NVMe RAID storage, the SSD7580C maximizes the potential of each PCIe x16 slot with direct connect and backplane connection flexibility.
Key Features
- PCIe 4.0 x16 interface with up to 28GB/s bandwidth for ultra-fast data transfer
- 8x U.2/U.3 NVMe ports supporting high-density storage configurations
- Bootable NVMe RAID controller with hot-plug and hot-swap capability
- Low-profile design optimized for server and workstation integration
- Direct connect and backplane connection options for flexible deployment
- Dedicated PCIe 4.0 x16 interface maximizes performance per slot
- Enterprise-grade reliability for mission-critical storage environments
Technical Specifications
| Specification |
Details |
| Manufacturer |
HighPoint Technologies |
| Part Number |
SSD7580C |
| Interface |
PCIe 4.0 x16 |
| NVMe Ports |
8x U.2/U.3 ports |
| Max Transfer Rate |
28GB/s |
| Form Factor |
Low-profile adapter card |
| Connection Types |
Direct connect and backplane options |
| Hot-Plug Support |
Yes |
| Hot-Swap Support |
Yes |
| Bootable |
Yes |
Frequently Asked Questions
What is a PCIe 4.0 NVMe RAID adapter used for?
A PCIe 4.0 NVMe RAID adapter like the SSD7580C enables servers and workstations to connect multiple high-speed NVMe drives in RAID configurations. This provides increased storage capacity, improved performance through parallel data access, and data redundancy for mission-critical applications.
How many NVMe drives can the SSD7580C support?
The SSD7580C features 8x U.2/U.3 NVMe ports, allowing you to connect up to 8 high-capacity NVMe drives simultaneously. This high-density configuration maximizes storage capacity within a single PCIe x16 slot.
Is the HighPoint SSD7580C bootable?
Yes, the SSD7580C is a bootable NVMe RAID controller, meaning you can configure your operating system and applications to run directly from the RAID array connected to this adapter, providing both performance and reliability benefits.
What are the benefits of hot-swap capability?
The hot-swap and hot-plug support on the SSD7580C allows you to replace or add NVMe drives without powering down your system. This is critical for server environments where downtime is costly, enabling maintenance and upgrades with zero interruption to operations.
