HighPoint SSD7502 NVMe RAID AIC
The SSD7502 is a PCIe 4.0 x16 2-port M.2 NVMe RAID AIC designed for professionals and enterprises demanding extreme storage performance. This half-height, low-profile adapter card delivers sustained transfer speeds up to 14,000 MB/s with dual Gen4 NVMe SSDs, making it ideal for video production, data centers, high-frequency trading, and intensive database applications. Each M.2 port receives dedicated PCIe 4.0 x4 lanes, ensuring peak performance without bottlenecks. Whether you need bootable RAID configurations for Windows and Linux or flexible single-disk setups, the SSD7502 provides enterprise-grade reliability in a compact form factor.
Key Features
- PCIe 4.0 x16 interface with dedicated x4 lanes per port for maximum throughput
- Dual M.2 NVMe RAID controller supporting 2242, 2260, and 2280 form factors
- Bootable RAID support for Windows and Linux operating systems
- RAID 0, RAID 1, and single-disk configuration modes
- Half-height low-profile design fits standard server and workstation slots
- Up to 14,000 MB/s sustained transfer speeds with dual Gen4 SSDs
- No additional power connectors required—powered via PCIe slot
Technical Specifications
| Specification |
Details |
| Manufacturer |
HighPoint Technologies |
| Part Number |
SSD7502 |
| Interface |
PCIe 4.0 x16 |
| M.2 Ports |
2 (dual-port) |
| Supported M.2 Form Factors |
2242, 2260, 2280 |
| RAID Modes |
RAID 0, RAID 1, Single Disk |
| Max Transfer Speed |
14,000 MB/s (dual Gen4 SSDs) |
| Form Factor |
Half-height, low-profile AIC |
| OS Support |
Windows, Linux (bootable RAID) |
| Power Requirement |
PCIe slot powered |
Frequently Asked Questions
What is an NVMe RAID AIC and why do I need one?
An NVMe RAID AIC (Add-In Card) combines multiple M.2 NVMe SSDs into a single high-performance storage solution. The SSD7502 enables RAID configurations for data redundancy (RAID 1) or performance acceleration (RAID 0), delivering speeds up to 14,000 MB/s—ideal for demanding workloads like 4K video editing, large database operations, and real-time analytics.
Can I boot from the SSD7502 RAID controller?
Yes. The SSD7502 supports bootable RAID on both Windows and Linux platforms, allowing you to configure your operating system directly on the RAID array. This enables both performance and redundancy benefits from system startup.
How many M.2 NVMe SSDs can the SSD7502 hold?
The SSD7502 is a 2-port M.2 NVMe RAID controller, accommodating exactly two M.2 SSDs. It supports 2242, 2260, and 2280 form factors, giving you flexibility in SSD selection while maintaining the compact half-height profile.
What PCIe slot do I need for the SSD7502?
The SSD7502 requires a PCIe 4.0 x16 slot. It will function in PCIe 3.0 x16 slots with reduced performance. The dedicated x4 lanes per M.2 port ensure each SSD operates at full Gen4 speeds without contention.
