HighPoint RocketAIC 7749EW 15.36TB PCIe 4.0 x16 NVMe AIC SSD
The RocketAIC 7749EW is a high-capacity NVMe AIC SSD engineered for demanding AI edge servers, data centers, and high-performance workstations that require extreme storage throughput. This PCIe 4.0 x16 add-in card combines eight enterprise-grade NVMe SSDs into a single, full-height, full-length solution delivering sustained read speeds up to 28,000 MB/s and write speeds up to 27,000 MB/s. With 15.36TB of raw capacity, integrated RAID support, and enterprise-class thermal management, the RocketAIC 7749EW accelerates data-intensive workloads while maintaining reliability in mission-critical environments.
Key Features
- 15.36TB total capacity with eight enterprise NVMe SSDs
- Sustained read speeds up to 28,000 MB/s; write speeds up to 27,000 MB/s
- PCIe 4.0 x16 interface for maximum bandwidth utilization
- Full-height, full-length, dual-width form factor for standard server slots
- RAID 0, 1, and 10 configurations for flexibility and data protection
- Integrated aluminum enclosure with thermal pad and active cooling fan
- WebGUI management software for easy monitoring and configuration
- Optimized for AI inference, machine learning, and real-time analytics
Technical Specifications
| Specification |
Details |
| Manufacturer |
HighPoint Technologies |
| Part Number |
RA7749EW-K15T3-0A |
| Product Name |
RocketAIC 7749EW 15.36TB PCIe 4.0 x16 NVMe AIC SSD |
| Total Capacity |
15.36TB |
| Interface |
PCIe 4.0 x16 |
| Form Factor |
Full-height, full-length, dual-width add-in card |
| NVMe Drives |
Eight enterprise SSDs |
| Max Read Speed |
28,000 MB/s (sustained) |
| Max Write Speed |
27,000 MB/s (sustained) |
| RAID Support |
RAID 0, 1, 10 |
| Cooling |
Aluminum enclosure with thermal pad and active fan |
| Management |
WebGUI software interface |
| Target Applications |
AI edge servers, data centers, high-performance workstations |
Frequently Asked Questions
What is an NVMe AIC SSD and how does it differ from standard SSDs?
An NVMe AIC SSD (Add-In Card) combines multiple NVMe drives on a single PCIe card, delivering significantly higher throughput than traditional SATA SSDs. The RocketAIC 7749EW uses eight NVMe drives on a PCIe 4.0 x16 interface, achieving up to 28,000 MB/s—ideal for AI workloads and data-intensive applications requiring extreme performance.
Is the RocketAIC 7749EW suitable for AI edge servers?
Yes. The RocketAIC 7749EW is specifically optimized for AI edge servers and machine learning inference tasks. Its 28GB/s read speed and 15.36TB capacity enable rapid model loading, real-time data processing, and efficient batch operations in edge computing environments.
What RAID configurations does this PCIe 4.0 NVMe AIC support?
The RocketAIC 7749EW supports RAID 0, 1, and 10 configurations. RAID 0 maximizes capacity and speed; RAID 1 provides mirroring for data protection; RAID 10 combines both for balanced performance and redundancy in enterprise data center deployments.
How is thermal management handled on this high-capacity NVMe AIC SSD?
The card features an integrated aluminum enclosure with a thermal pad and active cooling fan to maintain optimal operating temperatures during sustained high-speed operations, ensuring reliability in demanding data center and workstation environments.
