HighPoint RocketAIC 7540HW 16TB PCIe 4.0 x16 NVMe SSD
The HighPoint RocketAIC 7540HW is a full-height, full-length PCIe 4.0 x16 NVMe SSD add-in card delivering 16TB of high-performance storage for demanding Windows and Linux systems. Built with eight 2TB Samsung 990 PRO M.2 NVMe SSDs, this enterprise-grade solution achieves sequential read speeds up to 28,093 MB/s and write speeds up to 27,838 MB/s—ideal for data centers, content creation, and virtualization workloads. With dedicated RAID support, advanced thermal management, and WebGUI control, the RocketAIC 7540HW combines capacity, speed, and reliability in a single card.
Key Features
- 16TB total capacity with eight integrated 2TB Samsung 990 PRO M.2 NVMe SSDs
- PCIe Gen4 x16 dedicated host bandwidth for maximum throughput
- Sequential read speeds up to 28,093 MB/s; write speeds up to 27,838 MB/s
- RAID 0, 1, and 10 configuration support for data protection and performance
- Hyper-Cooling design with aluminum heatsink and low-noise fan
- 9600TB TBW endurance rating for enterprise reliability
- WebGUI management software for easy monitoring and control
- Full-height, full-length form factor for standard server slots
- Compatible with Windows and Linux operating systems
Technical Specifications
| Specification |
Details |
| Manufacturer |
HighPoint Technologies |
| Part Number |
RA7540HW-A16T0-0E |
| Product Name |
RocketAIC 7540HW 16TB PCIe 4.0 x16 NVMe SSD |
| Total Capacity |
16TB |
| Storage Media |
Eight 2TB Samsung 990 PRO M.2 NVMe SSDs |
| Interface |
PCIe Gen4 x16 |
| Sequential Read Speed |
Up to 28,093 MB/s |
| Sequential Write Speed |
Up to 27,838 MB/s |
| RAID Support |
RAID 0, 1, 10 |
| Endurance |
9600TB TBW |
| Cooling |
Hyper-Cooling with aluminum heatsink and fan |
| Management |
WebGUI software |
| Form Factor |
Full-height, full-length add-in card |
| OS Support |
Windows, Linux |
Frequently Asked Questions
What is the HighPoint RocketAIC 7540HW used for?
The RocketAIC 7540HW is designed for high-performance storage in data centers, virtualization environments, content creation studios, and servers requiring fast, reliable 16TB NVMe SSD capacity with RAID protection.
How fast is the PCIe 4.0 x16 NVMe SSD?
This 16TB NVMe SSD delivers sequential read speeds up to 28,093 MB/s and write speeds up to 27,838 MB/s, leveraging full PCIe Gen4 x16 bandwidth for maximum throughput.
Does the RocketAIC 7540HW support RAID?
Yes, the card supports RAID 0, 1, and 10 configurations, allowing you to optimize for performance, redundancy, or a balance of both depending on your workload requirements.
What cooling solution does the RocketAIC 7540HW include?
The card features a Hyper-Cooling design with an aluminum heatsink and low-decibel fan to maintain optimal temperatures during sustained high-speed operations.
