Bosch Midspan, 60W, Single Port, AC In
60 W Midspan The 60 W midspan (NPD-6001B) enables remote High Power over Ethernet (High PoE) for various Bosch IP/HD PTZ cameras. Generating a maximum of 60 W, it complies to both the IEEE 802.3af and the IEEE 802.3at standards, while doubling the available power. Rated for indoor installation only, the midspan can be installed indoors and wired to a camera installed outdoors.
The midspan provides surge protection, optimal for installation of outdoor powered devices. The midspan has a single port and is designed to carry data and power over a standard CAT5e (or better) cable, delivered through all 4 pairs.
- Supports high-power PoE/PoH and complies to both the IEEE 802.3af and the IEEE 802.3at standards
- Lightning protection
- Detects and protects non-standard Ethernet terminals automatically
- Mounts to a wall, shelf, bench or desktop
Product Type: PoE Injector
Environmentally Friendly: Yes
Environmental Certification: GS
Certifications & Standards:
Electromagnetic Compatibility (EMC)
- FCC Part 15
- ICES-003
- CE
- EN 55032 Class B (emission)
- EN 55024 (Immunity)
- VCCI
Product Safety
- UL/cUL
- GS Mark per EN 60950-1
Regulatory Compliance
- IEEE 802.3af (PoE)
- IEEE 802.3at (PoE+, including 2-event)
- CE
Lightning protection
- Meets GR-1089-CORE lightning protection demands
- EN 61000-4-5 (10/700 µsec, 4kv)
- Surge protection: IEC 61643-21
- ITU-T K.45 International standard
Brand Name: Bosch
Compatibility:
Bosch IP/HD PTZ Cameras: - AUTODOME 7000
- MIC7000 (without Illuminators)
Length: 5.9"
Manufacturer: The Bosch Group
Product Model: NPD-6001B
Product Name: Midspan, 60W, Single Port, AC In
Mount Type: Wall/Shelf/Bench/Desktop-mountable
Manufacturer Part Number: NPD-6001B
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Package Contents:
- NPD-6001B High PoE Midspan
- 1 x 120V Power Cord
- 1 x 230V Power Cord
- 1 x Quick Installation Guide
Weight (Approximate): 11.99 oz
