Gefen VGA & Audio to HD Scaler / Converter
Scale and convert video and audio from a VGA source for use with an HDMI Display
The Gefen EXT-VGAA-HD-SC scales and converts video from a VGA source to digital video from an HDMI output. It can also embed analog L/R audio into HDMI. Video can be scaled up to 1080p Full HD and 1920 x 1200 (WUXGA). An intuitive and comprehensive on-screen display (OSD) menu allows easy set-up and control. This product can be configured and updated using the Gefen Syner-G™ software suite. The Gefen Syner-G™ is a powerful set of software tools specifically designed to help discover, configure/customize, manage, monitor, and upgrade Gefen products. Wide power supply operating range of 6V to 24V DC offers installation flexibility for mobile use, in complex studio systems with a common power supply, and with remotely located power sources. A locking power supply connector, small footprint, and a surface-mountable enclosure facilitate easy and secure installation.
How It Works
Use the included VGA cable to connect a VGA source to the VGA input. Connect the included 3.5mm mini-stereo cable from the source to the L/R audio input. Use a Gefen locking HDMI cable to connect a display to the HDMI output. Connect the included 12V DC power supply to the unit and to an available electrical outlet. The power LED will glow in blue once the power supply is plugged in. Once the unit is connected, powered on, and displaying video, press the Menu button to bring up the On-Screen Display (OSD). The Up and Dn (down) buttons are used to navigate through the various functions of the OSD.
- Wide power supply operating range (6V to 24V DC)
- USB port for use with Gefen Syner-G™
- Embeds 2-channel analog stereo audio in HDMI signal
- Gefen Syner-G™ simplifies in-field firmware updates and advanced EDID management including custom input timings
- Test Pattern Generator for quick system configuration
- Aspect Ratio Control: Full Screen, Panoramic, Letter/Pillar, Extract/Crop
- On-screen display (OSD) menu allows easy set-up and control
- Output resolutions up to 1080p60 and 1920 x 1200 (WUXGA)
- Input resolutions up to 1920 x 1200 (WUXGA)
- Converts and scales VGA and L/R analog audio to HDMI
Product Type: Video Scaler
Brand Name: Gefen
Form Factor: External
Manufacturer: Gefen, Inc
Product Name: VGA & Audio to HD Scaler / Converter
Manufacturer Part Number: EXT-VGAA-HD-SC
Manufacturer Website Address: http://www.gefen.com
Packaged Quantity: 1
Package Contents:
- VGA & Audio to HD Scaler / Converter
- 1 x 6 ft. Locking VGA Cable (M-M) (CAB-VGA-06MM-O)
- 1 x 3.5 MM Mini Stereo Cable (M-M) (CAB-MP-ST-06MM-BC)
- 1 x 12V DC Power Supply (EXT-PS121.5AIP-3P)
- 1 x Quick-Start Guide (QSG-EXT-VGAA-HD-SC)
Limited Warranty: 2 Year
Weight (Approximate): 0.40 lb
