Name: Fractal Design Define R5 No Power Supply Atx Mid Tower (Black)
Brand: Fractal Design
SKU: FD-CA-DEF-R5-BK
Price: 289.00 CAD
Availability: InStock

Fractal Design Define R5 No Power Supply Atx Mid Tower (Black)

Roll over image to zoom in Click on image to zoom

✅⚠️DO NOT ORDER WITHOUT CONFIRMING STOCK. This item has limited availability. Contact us via chat or sales@tecisoft.com to verify before purchasing. Unconfirmed orders may be canceled.

Mfr Part Number: FD-CA-DEF-R5-BK
Features:
- Optimally designed for silent computing with high density noise-reducing material throughout the case for maximum sound absorption, while not compromising on airflow and cooling capabilities
- Extensive water cooling support for a case of this size; housing radiators up to 420mm in the top and 360mm in the front
- Equipped with new tool-less ModuVent fan slot covers allowing the user to install more fans if desired or keep fan slots covered to maximize sound absorption
- Including two Fractal Design Dynamic GP14 140mm fans developed for superlative airflow while still maintaining low noise levels
- Maintaining a dust-free interior with the help of dust filters that cover front and bottom air intakes that are easy to access from the front on the case
- Newly configured front door with dual side mounting to better fit your work space
- Highlighting 2 dedicated SSD mounts cleanly placed behind the motherboard tray that feature innovative new brackets delivering a tool-free installation and removal
- The HDD cage system holds up to eight 3.5" or 2.5" drives and is more adaptable than ever, allowing the user to modify the case layout according to personal preference with more places to relocate the cages
- The ODD cage can easily be removed to gain additional interior space; the area can be freed up to allow for increased airflow, to provide a new place for HDD cage mounting or to make more room for water cooling components
- Sturdy metal HDD trays provide excellent dampening features for the hard drives while providing better airflow through the cage with an updated, more open design
- The new and innovative Quick Release System on the left side of the case provides secure mounting of the left side panel, yet grants quick and easy access to the system
- Three-speed fan controller is strategically integrated in the front panel and supports up to 3 fans
Case Type: ATX Mid Tower
Color: Black
Material: N/A
M/B Type: ATX, Micro ATX, Mini ITX
Drive Bays:
- External Bays: 2x 5.25"
- Internal Bays: 8x 3.5", 2x 2.5"
Expansion Slots: 7
Cooling System:
- Top: 3x 120/140mm Fan Vents (Fans not included)
- Front: 2x 120/140mm Fan Vents (1x Fractal Design Dynamic GP14 Fan is included, 1000 RPM)
- Rear: 1x 120/140mm Fractal Design Dynamic GP14 Fan (1000 RPM)
- Bottom: 2x 120/140mm Fan Vents (Fans not included)
- Side: 1x 120/140mm Fan Vent (Fan not included)
- Fan Controller: 3x Step Fan Controller for up to 3 Fans
- Dust filters: Bottom and front intakes
- Water Cooling Compatibility:
  - Front: 120/140/240/280/360mm Radiators (of all thicknesses, requires removal of drive bays)
  - Top: 120/140/240/280/360/420mm Radiators (A thickness limitation of 55mm for both radiator + fan applies on 420, 280 and 140 mm radiators) (420 and 360 mm radiators require removal of the ODD bay)
  - Bottom: 1x 120/240mm Radiator (Use of radiators in the bottom position limits the PSU length to 165 mm)
  - Rear: 1x 120/140mm Radiator
Side Windows: No
Front I/O Panel: 2x USB 3.0 Ports, 2x USB 2.0 Ports, Audio In & Out
Maximum Compatibility:
- VGA Card Length: 310 mm (w/ top HDD cage); 440 mm (w/o top HDD cage)
- CPU Cooler Height: 180 mm
- Space for Cable Routing behind the Motherboard Plate: 20 - 35 mm
Power Supply: None, 300mm Max PSU Length
Dimensions (WxDxH): 232.0 x 521.0 x 451.0 mm
Weight: 11.2 kg

General Information

Manufacturer	Fractal Design
Manufacturer Part Number	FD-CA-DEF-R5-BK
Manufacturer Website Address	http://www.fractal-design.com
Brand Name	Fractal Design
Product Line	Define R5
Product Name	Define R5 Black
Product Type	Computer Case
UPC	817301012584

Total Number of USB Ports	4

Product Color	Black
Height	17.8"
Width	9.1"
Depth	20.5"
Weight (Approximate)	24.69 lb

Miscellaneous

Package Contents	Define R5 Black Velcro Straps User Manual Accessory Box

Warranty

Limited Warranty	2 Year
