Finisar 100GBASE-LR4 10km Gen2 CFP2 Optical Transceiver FTLC1151SDPL

Finisar 100GBASE-LR4 10km Gen2 CFP2 Optical Transceiver
Finisar's FTLC1151SDPL QSFP28 transceiver modules are designed for use in 100 Gigabit Ethernet and 4x28G OTN client interfaces over single mode fiber. They are compliant with the QSFP28 MSA, IEEE 802.3ba 100GBASE-LR4 and OTU4 4I1- 9D1F requirements specified in ITU-T Recommendations G.959.1/G.709 and Supplement 39 (G.sup39). Digital diagnostic functions are available via the I2C interface, as specified by the QSFP28 MSA and Finisar Application Note AN-2152 5. The transceiver is RoHS-6 compliant per Directive 2011/65/EC and Finisar Application Note AN-2038.

• Duplex LC receptacles


• 4x28G retimed electrical interface


• 4x28Gb/s DFB-based LAN-WDM transmitter


• Maximum link length of 10km on Single Mode Fiber (SMF)


• Single 3.3V power supply


• Commercial case temperature range of 0°C to 70°C


• Power dissipation < 3.5W


• RoHS-6 compliant


• Supports 103.1Gb/s and 112Gb/s aggregate bit rates


• Hot-pluggable QSFP28 form factor

Product Type: CFP2
Environmentally Friendly: Yes
Environmental Certification: RoHS-6
Brand Name: Finisar
Compatibility:

MSA Compliant
