Extreme Networks 5420F 24-Port PoE Switch with 90W and 30W PoE
The Extreme Networks 5420F-8W-16P-4XE is a high-performance 24-port managed switch engineered for enterprise edge deployments requiring extensive Power over Ethernet capabilities. With eight 90W 802.3bt Type 4 PoE ports and sixteen 30W Type 2 PoE+ ports, this 24-port PoE switch delivers 480W total PoE budget—ideal for powering demanding IoT devices, IP cameras, access points, and VoIP phones across large campus networks. The integrated four 10G SFP+ uplink ports provide high-speed backbone connectivity, while Layer 3 routing support enables advanced network segmentation and security. Perfect for organizations needing scalable, power-efficient edge switching with MACsec encryption on high-power ports.
Key Features
- Eight 10/100/1000BASE-T ports with 802.3bt Type 4 PoE (90W) and MACsec support
- Sixteen 10/100/1000BASE-T ports with Type 2 PoE+ (30W) for standard devices
- Four 10G SFP+ uplink ports for high-speed backbone and redundancy
-
480W total PoE budget for simultaneous multi-device power delivery
- Layer 3 routing with advanced QoS and traffic management
- MACsec encryption on high-power ports for secure device communication
- Compact edge switch design suitable for wiring closets and distributed deployments
- TAA-compliant for government and regulated procurement
Technical Specifications
| Specification |
Details |
| Manufacturer |
Extreme Networks Inc |
| Part Number |
5420F-8W-16P-4XE-TAA |
| Product Series |
ExtremeSwitching 5420F |
| Port Configuration |
24 x 10/100/1000BASE-T (8x 90W PoE + 16x 30W PoE+) + 4x 10G SFP+ |
| PoE Type 4 Ports |
8 ports @ 90W with 802.3bt support and MACsec |
| PoE Type 2 Ports |
16 ports @ 30W with 802.3at+ support |
| Total PoE Budget |
480W |
| Uplink Ports |
4 x 10G SFP+ for backbone connectivity |
| Layer Support |
Layer 3 with routing, QoS, and VLAN support |
| Security Features |
MACsec encryption, port security, access control lists |
| Compliance |
TAA-compliant, IEEE 802.3bt, 802.3at+, 802.3af |
Frequently Asked Questions
What is the difference between 90W PoE and 30W PoE ports on this switch?
The eight 90W ports support 802.3bt Type 4 PoE, delivering maximum power for demanding devices like high-end IP cameras, wireless access points, and industrial IoT equipment. The sixteen 30W ports use Type 2 PoE+ for standard devices like basic cameras and phones. This mixed configuration optimizes power distribution across 24 ports with a 480W budget.
Can I use this 24-port PoE switch for IP camera installations?
Yes, the 5420F-8W-16P-4XE is excellent for IP camera deployments. The eight 90W ports support high-power PTZ cameras and multi-sensor units, while the sixteen 30W ports handle standard fixed cameras. The 480W PoE budget allows simultaneous powering of multiple cameras without additional power supplies.
What does MACsec do on the high-power PoE ports?
MACsec (Media Access Control Security) on the eight 90W ports encrypts Layer 2 traffic, protecting sensitive data transmitted to powered devices. This is critical for secure IoT and surveillance deployments where device authentication and data integrity are essential.
How do the 10G SFP+ uplink ports improve network performance?
The four 10G SFP+ uplinks provide 40Gbps aggregate bandwidth for connecting to core switches or data center infrastructure. This prevents bottlenecks when multiple high-power PoE devices transmit data simultaneously, ensuring consistent performance across the edge switch.
