Rack Solutions Extra Heavy Duty Sliding Shelf (500 lbs)
Fits any 4Post rack or cabinet
- Fits square, round, threaded holes
- Mounting depth range: 18 - 30" (457 -762 mm)
- Surface area: 28" L x 17.6" W (711 x 447 mm)
Sliding shelf for heavy equipment
- 500 lbs (227 kgs) capacity
- Heavy duty, ball bearing slides, (CMA) cable management arm
- Supports items up to 28" (711 mm) deep, 17.6" (447 mm) wide
- Shelf extends to 29" (737 mm)
Applications
- Large, tower servers
- Non-rack-mountable equipment
FeaturesThe RackSolutions Extra Heavy Duty Sliding Shelf is an ideal solution in environments where servers, computers and other equipment needs to be stored on a sturdy shelf that can be slid forward for easy access during operation. The Extra Heavy Duty Sliding Shelf are compatible with square, threaded and round hole-based server racks, and feature an extension reach of 29". The shelf itself is 28" deep, letting users safely store most computers and other equipment. The versatile solution is also durable, as it is built of rolled steel and capable of holding 500 lbs of hardware. In terms of compatibility, the Sliding Rack Mount Shelves will fit on almost any standard EIA standard server racks.
Product Type: Rack Shelf
Maximum Weight Capacity: 500 lb
Product Color: Black Powder Coat
Product Material: Cold-rolled Steel (CRS)
Country Of Origin: United States
Assembly Required: Yes
Rack Height: 4U
Brand Name: Rack Solutions
Form Factor: Rack-mountable
Manufacturer: Innovation First, Inc
Product Name: Extra Heavy Duty Sliding Shelf (500 lbs)
Manufacturer Part Number: 115-4044
Manufacturer Website Address: http://www.racksolutions.com
Package Contents:
- Extra Heavy Duty Sliding Shelf (500 lbs)
- 10-32 & 12-24 Screws
- Cage Nuts
