MTP MALE 6X LC-UPC DUPLEX SMF CASSETTE MODULE
The ENET MTP MALE 6X LC-UPC DUPLEX SMF CASSETTE MODULE delivers high-density fiber connectivity for modern data center and enterprise network infrastructures. This MTP cassette module provides reliable single-mode fiber connections with six duplex LC-UPC ports, enabling seamless integration into existing network architectures. Ideal for organizations requiring scalable, high-performance fiber optic solutions, this LC-UPC duplex cassette ensures maximum signal integrity and minimal insertion loss for mission-critical applications.
Key Features
- 6X duplex LC-UPC ports for high-density connectivity
- Single-mode fiber (SMF) optimized for long-distance transmission
- MTP male connector interface for seamless cassette integration
- Low insertion loss and return loss performance
- Hot-swappable design for flexible network reconfiguration
- Industry-standard form factor compatible with major chassis systems
- Durable construction rated for 500+ mating cycles
- RoHS compliant and environmentally certified
Technical Specifications
| Specification |
Details |
| Manufacturer |
ENET SOLUTIONS |
| Part Number |
MTPM6X-LC-SMF-CASS |
| Connector Type |
MTP Male (Input) / LC-UPC Duplex (Output) |
| Port Configuration |
6X Duplex (12 fiber strands) |
| Fiber Type |
Single-Mode Fiber (SMF) |
| Insertion Loss |
<0.35dB per port |
| Return Loss |
>50dB |
| Operating Wavelength |
1310nm / 1550nm |
| Temperature Range |
0°C to 70°C |
| Mating Cycles |
500+ |
| Form Factor |
Cassette Module |
Frequently Asked Questions
What is an MTP cassette module used for?
An MTP cassette module is used to convert high-density MTP connections into individual LC-UPC duplex ports, enabling flexible fiber optic connectivity in data centers and network infrastructure. It allows organizations to maximize port density while maintaining compatibility with standard LC-based equipment.
What are the advantages of LC-UPC duplex connectors?
LC-UPC duplex connectors offer superior performance with low insertion loss, high return loss, and reliable connections. The duplex configuration enables bidirectional communication over single-mode fiber, making them ideal for long-distance, high-speed network applications in enterprise and carrier environments.
Is this cassette module compatible with existing network infrastructure?
Yes, the ENET MTP MALE 6X LC-UPC DUPLEX SMF CASSETTE MODULE features an industry-standard form factor and hot-swappable design, making it compatible with major chassis systems and existing fiber optic infrastructure. Verify your equipment specifications before installation.
What fiber type does this module support?
This cassette module is optimized for single-mode fiber (SMF), which provides superior performance for long-distance transmission at 1310nm and 1550nm wavelengths, making it suitable for enterprise backbone networks and data center interconnects.
