8CH DWDM MUX CH20-CH27 19 1U Rack-Mountable Chassis SM LC/UPC
The ENET 8-channel DWDM multiplexer is engineered for telecommunications professionals and data center operators who demand reliable, high-density wavelength division multiplexing solutions. This rack-mountable DWDM chassis consolidates eight optical channels (CH20-CH27) into a single 1U form factor, delivering cost-effective wavelength management for long-haul and metro optical networks. Perfect for network architects implementing scalable fiber optic infrastructure, this DWDM mux supports single-mode LC/UPC connectors for seamless integration into existing telecom environments.
Key Features
- 8-channel DWDM multiplexing capability (channels 20-27)
- Compact 1U rack-mountable chassis design
- Single-mode fiber (SM) LC/UPC connector interfaces
- High-density wavelength consolidation for metro and long-haul applications
- Industry-standard 19-inch rack compatibility
- Passive optical architecture for reliable performance
- Supports ITU-T grid wavelength standards
- Low insertion loss and high channel isolation
Technical Specifications
| Specification |
Details |
| Manufacturer |
ENET SOLUTIONS |
| Part Number |
D1MX08-20SCLC |
| Channel Count |
8 channels |
| Channel Range |
CH20-CH27 (ITU-T Grid) |
| Form Factor |
1U Rack-Mountable Chassis |
| Rack Width |
19 inches |
| Fiber Type |
Single-Mode (SM) |
| Connector Type |
LC/UPC |
| Optical Interface |
DWDM Multiplexer/Demultiplexer |
| Operating Wavelengths |
1560.61 nm - 1563.86 nm (CH20-CH27) |
Frequently Asked Questions
What is a DWDM multiplexer and how does it work?
A DWDM (Dense Wavelength Division Multiplexing) multiplexer combines multiple optical signals at different wavelengths onto a single fiber strand, dramatically increasing bandwidth capacity. This 8-channel DWDM mux accepts eight separate optical channels and merges them for transmission over long distances, then demultiplexes them back at the receiving end.
Is this DWDM chassis suitable for data center applications?
Yes. The 1U rack-mountable DWDM chassis is ideal for data center interconnect (DCI) scenarios, metro networks, and carrier-grade telecommunications deployments. Its compact form factor and passive architecture make it a reliable choice for high-density optical networking environments.
What does LC/UPC connector compatibility mean?
LC/UPC connectors are industry-standard fiber optic interfaces featuring Ultra-Polished (UPC) ferrule geometry, ensuring minimal back-reflection and signal loss. This 8-channel DWDM multiplexer with LC/UPC connectors integrates seamlessly with standard telecommunications infrastructure and test equipment.
Can this DWDM mux be integrated into existing optical networks?
Absolutely. The ENET DWDM multiplexer supports ITU-T grid wavelength standards (CH20-CH27), making it compatible with carrier-class optical networks. Its passive design requires no external power, simplifying deployment in existing rack environments.
