This elo monitor touch screen is perfect for system integrators, kiosk manufacturers, and businesses requiring reliable interactive display solutions for industrial and commercial applications. Our Elo 2294L delivers:
-
Open-frame design providing maximum integration flexibility for custom kiosk and embedded applications
-
IntelliTouch surface acoustic wave technology ensuring precise, durable touch response in demanding environments
-
Industrial-grade construction engineered for continuous 24/7 operation in harsh commercial conditions
-
Digital signage compatibility supporting interactive content delivery and customer engagement solutions
Key Features
-
21.5-inch Full HD display delivering crystal-clear 1920x1080 resolution for detailed visual content and user interfaces
-
IntelliTouch surface acoustic wave technology providing accurate touch detection without screen overlay degradation
- Optimized for digital signage systems with robust performance for interactive advertising and information displays
- Consistent multi-touch capability enabling intuitive gesture control and advanced user interaction
-
Open-frame construction facilitating seamless integration into custom enclosures and specialized applications
Technical Specifications
| Manufacturer |
Elo Touch Solutions, Inc |
| Model Number |
E327914 (2294L) |
| Type |
21.5-Inch Open Frame Touch Screen Monitor |
| Screen Size |
21.5 inches diagonal |
| Resolution |
1920 x 1080 Full HD (1080p) |
| Touch Technology |
IntelliTouch Surface Acoustic Wave (SAW) |
| Panel Type |
LCD with LED backlight |
| Brightness |
250 cd/m² typical |
| Contrast Ratio |
1000:1 typical |
| Viewing Angles |
170° horizontal / 160° vertical |
| Response Time |
5ms typical |
| Touch Points |
Multi-touch (up to 10 points) |
| Touch Activation |
Finger, gloved hand, stylus |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Storage Temperature |
-20°C to 60°C (-4°F to 140°F) |
| Humidity |
10% to 90% non-condensing |
| Design |
Open Frame (Bezel-Free) |
| Mounting |
Panel mount, chassis mount, custom enclosure |
| Power Consumption |
25W typical operation |
| Connectivity |
VGA, DVI-D, USB (touch), power input |
| Compatible Systems |
Windows, Linux, Android, embedded systems, POS software |
Digital Signage Applications
Interactive Retail Displays: This digital signage systems monitor excels in retail environments where customers interact with product catalogs, wayfinding systems, and promotional content, providing engaging shopping experiences that drive sales and customer satisfaction.
Information Kiosks: Perfect for airports, hotels, hospitals, and public facilities where visitors need access to directories, maps, services information, and interactive assistance without staff intervention.
Use Cases & Applications
Point of Sale Integration: Ideal for touch screen point of sale system applications in restaurants, retail stores, and service businesses requiring customer-facing ordering interfaces, payment processing, and product selection capabilities.
Industrial Human Machine Interface: This best touch screen monitor serves excellently in manufacturing facilities, process control applications, and industrial automation where operators need reliable touch-based control interfaces for equipment monitoring and system management.
Gaming and Entertainment: Perfect for arcade machines, gaming kiosks, and entertainment venues where robust touch interaction and vibrant display quality enhance user engagement and operational reliability.
Healthcare Applications: Excellent for patient check-in systems, medical equipment interfaces, and healthcare information displays where hygiene, reliability, and ease of use are critical requirements.
Educational Environments: Ideal for interactive learning stations, digital classroom displays, and educational kiosks where engaging touch interaction enhances learning experiences and student participation.
IntelliTouch Technology Benefits
Surface Acoustic Wave Precision: IntelliTouch SAW technology uses ultrasonic waves across the glass surface to detect touch, providing exceptional accuracy and sensitivity without screen films or overlays that can degrade image quality or durability.
Multi-Touch Capability: Advanced touch detection supports up to 10 simultaneous touch points, enabling sophisticated gesture recognition, pinch-to-zoom functionality, and multi-user interaction scenarios.
Durability and Longevity: SAW technology has no moving parts and requires no pressure activation, ensuring reliable operation through millions of touches while maintaining optical clarity and touch sensitivity over extended periods.
Open Frame Design Advantages
Integration Flexibility: Open-frame construction eliminates bezels and external casings, enabling seamless integration into custom enclosures, kiosks, control panels, and embedded applications where space optimization is critical.
Custom Enclosure Compatibility: Panel mount design supports integration into specialized housings for harsh environments, outdoor applications, medical equipment, and industrial control systems requiring specific environmental protection ratings.
Cost-Effective Deployment: Open-frame design reduces material costs and enables efficient high-volume manufacturing for OEM applications while maintaining professional appearance and functionality.
Industrial-Grade Reliability
24/7 Operation Capability: Commercial-grade components and thermal management enable continuous operation essential for digital signage systems and critical applications requiring round-the-clock availability.
Environmental Resistance: Wide operating temperature range (0°C to 50°C) and humidity tolerance make this monitor suitable for challenging commercial environments including retail stores, warehouses, and semi-outdoor installations.
Vibration and Shock Resistance: Robust construction withstands transportation vibration, installation handling, and operational stresses common in industrial and commercial applications.
Display Performance
Full HD Resolution: 1920x1080 pixel resolution provides sharp text, detailed images, and clear user interface elements essential for professional applications and customer-facing displays.
LED Backlight Technology: Energy-efficient LED backlighting offers consistent brightness, extended lifespan, and reduced power consumption compared to traditional CCFL backlights.
Wide Viewing Angles: 170° horizontal and 160° vertical viewing angles ensure consistent image quality and touch accuracy from multiple viewing positions, critical for public-access applications.
Touch Interaction Capabilities
Universal Input Support: Responds accurately to finger touch, gloved hands, and stylus input, making this elo monitor touch screen suitable for diverse user scenarios including medical, industrial, and food service environments.
Ghost Touch Prevention: Advanced touch algorithms prevent false touch detection from water droplets, dirt, or other contaminants, ensuring reliable operation in challenging environments.
Touch Through Glass: SAW technology enables touch detection through protective glass overlays, allowing custom protection while maintaining full touch functionality.
Connectivity and Integration
Standard Video Inputs: VGA and DVI-D connectivity ensure compatibility with various computer systems, media players, and embedded controllers commonly used in commercial applications.
USB Touch Interface: Standard USB connection for touch data transmission provides plug-and-play compatibility with Windows, Linux, and embedded systems without requiring special drivers or software.
Power Efficiency: 25W typical power consumption reduces operating costs and heat generation while supporting green technology initiatives and battery-powered applications.
Software Compatibility
Operating System Support: Native compatibility with Windows, Linux, and Android operating systems ensures seamless integration with existing software platforms and custom application development.
POS Software Integration: Optimized for touch screen point of sale system software including retail management, restaurant ordering, and inventory control applications requiring reliable touch input.
Digital Signage Software: Compatible with major digital signage content management systems enabling dynamic content delivery, scheduling, and remote management capabilities.
Installation and Mounting
Panel Mount Design: Standard panel mounting enables integration into custom kiosks, control panels, and equipment housings with secure mechanical attachment and professional appearance.
Chassis Mount Options: Alternative mounting configurations support various installation scenarios including wall mounting, rack mounting, and embedded applications.
Cable Management: Organized connector layout and cable routing options facilitate clean installations and maintenance access in space-constrained applications.
Elo Quality and Support
Touch Technology Leadership: Elo Touch Solutions' decades of touch screen expertise ensure proven reliability, continuous innovation, and comprehensive technical support for mission-critical applications.
Global Service Network: Worldwide service and support infrastructure provides local assistance, replacement parts, and technical expertise for large-scale deployments and ongoing operations.
Warranty Protection: Comprehensive warranty coverage protects investment and ensures reliable operation with professional repair services and replacement options.
Comparative Advantages
Retail Environments: Superior to standard monitors by providing interactive customer engagement capabilities while maintaining industrial-grade reliability for high-traffic commercial applications.
Industrial Settings: Advantages over consumer touch displays include proven durability, wide temperature operation, and compatibility with specialized industrial software and control systems.
Healthcare Applications: Better infection control through smooth glass surface, reliable operation with gloved hands, and compatibility with medical-grade cleaning solutions and disinfection procedures.
OEM and Integration Benefits
Reduced Development Time: Proven touch technology and standard interfaces accelerate product development cycles for OEM applications requiring reliable interactive displays.
Cost Optimization: Open-frame design and high-volume availability enable competitive pricing for large-scale deployments while maintaining quality and reliability standards.
Technical Support: Comprehensive documentation, development tools, and engineering support assist with custom integration and application-specific requirements.
Frequently Asked Questions
Q: What makes this suitable for digital signage applications?
A: This elo monitor touch screen combines high-resolution display quality, reliable IntelliTouch technology, and industrial-grade construction perfect for interactive advertising, wayfinding, and customer engagement applications requiring 24/7 operation.
Q: How does IntelliTouch technology differ from other touch solutions?
A: IntelliTouch SAW technology provides superior accuracy and durability without screen overlays that can degrade image quality, supporting multi-touch gestures and maintaining sensitivity through millions of touches.
Q: What are the advantages of open-frame design?
A: Open-frame construction enables seamless integration into custom kiosks and equipment housings, reduces material costs, and provides maximum design flexibility for specialized applications.
Q: Can this monitor operate in harsh environments?
A: Yes, this best touch screen monitor operates reliably in temperatures from 0°C to 50°C with 10% to 90% humidity, making it suitable for challenging commercial and semi-industrial environments.
Q: What input methods are supported for touch interaction?
A: The monitor responds accurately to finger touch, gloved hands, and stylus input, making it suitable for medical, food service, industrial, and general commercial applications.
Q: How does this integrate with point of sale systems?
A: This touch screen point of sale system monitor provides standard USB touch interface and video connectivity compatible with major POS software platforms for retail, restaurant, and service business applications.
Elo 2294L 21.5" open frame touch screen monitor with IntelliTouch SAW technology for digital signage, kiosks, and industrial applications requiring reliable interactive displays.
