The Eaton T2235-3497 ATS Rack PDU is perfect for data center administrators and IT professionals who need redundant power protection for mission-critical server applications. This automatic transfer switch PDU delivers:
-
Dual L5-30P input sources providing automatic failover between primary and backup power feeds
-
24A power capacity supporting high-density server and network equipment deployments
-
1U rackmount design maximizing rack space efficiency in data center environments
-
18ft cable length ensuring flexible installation and power source connectivity
Key Features
-
Automatic transfer switch functionality seamlessly switching between dual power sources for continuous operation
-
Dual L5-30P inputs supporting redundant 30-amp power feeds for maximum reliability
-
Dual L5-20R outputs providing protected power distribution to critical equipment
-
Single-phase 110-125V operation supporting standard North American power systems
-
18-foot input cable offering installation flexibility and extended reach
-
Horizontal 1U mounting optimizing rack space utilization and cable management
Technical Specifications
| Manufacturer |
Eaton |
| Part Number |
T2235-3497 |
| Product Type |
ATS Rack PDU (Automatic Transfer Switch) |
| Input Voltage |
110-125V AC Single Phase |
| Current Capacity |
24A |
| Input Configuration |
Dual L5-30P |
| Output Configuration |
Dual L5-20R |
| Cable Length |
18 feet |
| Mounting |
1U Horizontal Rackmount |
| Transfer Type |
Automatic Power Transfer |
Frequently Asked Questions
Q: How does automatic transfer switch functionality work in this PDU?
A: The ATS rack PDU continuously monitors both input power sources and automatically transfers to the backup feed if the primary source fails, ensuring uninterrupted power to connected equipment without manual intervention in dual input power distribution unit applications.
Q: What equipment can this 24A ATS PDU support?
A: This automatic transfer switch PDU with 24A capacity can support servers, network switches, storage systems, and other critical IT equipment requiring redundant power protection, making it ideal for rack mounted power distribution unit deployments.
Q: What are the advantages of L5-30P and L5-20R connectors?
A: The L5-30P input connectors provide secure 30-amp connections for high-power applications, while the L5-20R output connectors deliver reliable 20-amp power distribution, ensuring proper load balancing in 1U rackmount configurations.
Q: How does the 18ft cable benefit installation flexibility?
A: The extended 18-foot cable allows the ePDU to be positioned optimally within the rack while reaching distant power sources, providing installation flexibility and accommodating various data center power distribution layouts in redundant power PDU setups.
Eaton T2235-3497 ATS Rack PDU with dual L5-30P input, dual L5-20R output, 24A capacity, and 1U rackmount automatic transfer switch design.
