✅⚠️Availability Check: This item may have limited stock. Reach out to confirm before purchasing: Chat or email [email protected]
- Mfr Part Number: K199
- CPU Application: Intel Socket 1156 1U Server Support Intel Core i3 530 / 540, Core i5 650/ 660/ 661/ 670/ 750; Xeon Processor 3400 Series; Core i7 870 / 860
- Heat Sink Material: Copper
- Fan:
- Speed:
- At Duty Cycle 0-20%: 1000 rpm
- At Duty Cycle 50%: 2500 rpm
- At Duty Cycle 100%: 5000 rpm
- Bearing: 2x Ball
- Air Flow:
- At Duty Cycle 0-20%: 5.355 cfm
- At Duty Cycle 50%: 7.654 cfm
- At Duty Cycle 100%: 14.719 cfm
- Noise Level:
- At Duty Cycle 0-20%: 20.71 dBA
- At Duty Cycle 50%: 37.5 dBA
- At Duty Cycle 100%: 51.7 dBA
- Air Pressure:
- At Duty Cycle 0-20%: 2.083 mm-H2O
- At Duty Cycle 50%: 9.780 mm-H2O
- At Duty Cycle 100%: 36.168 mm-H2O
- Rated Voltage: 12 V
- Power:
- At Duty Cycle 0-20%: 0.60 W
- At Duty Cycle 50%: 1.44 W
- At Duty Cycle 100%: 9.60 W
- Lead Wire Pin Out:
- Pin1-Black (-)
- Pin2-Yellow (+)
- Pin3-Green (Techometer/Signal output)
- Pin4-Blue (PWM)
- Fan Dimensions: 80x80x15 mm
- Overall Dimensions: 85.0 x 81.5 x 28.5 mm
- Weight: 355g 5g
- RoHS Compliant
