Name: Dynatron A24 Recommend For Amd Processor, Socket Am4. New Innovation 60X60X28Mm Pwm Fan, Aluminum
Brand: Dynatron
SKU: A24
Price: 2246.00 CAD
Availability: InStock

Dynatron A24 Recommend For Amd Processor, Socket Am4. New Innovation 60X60X28Mm Pwm Fan, Aluminum

Roll over image to zoom in Click on image to zoom

Mfr Part Number: A24
Feature:
- Supports AMD Socket AM4 CPU
- Aluminum Stacked Fin with heat Pipes
- 4-pin PWM Controlled Fan
- Supports up to TDP 95 Watts
- Recommended for 2U Server and up
CPU Support : AMD
CPU Socket : AM4
Solution : 2U Server and Up
Dimensions : 107 x 78 x 67 mm
Weight : 400 g
Material : Aluminum Stacked Fin with Heat Pipes directly contact CPU
Fan Dimension : 60 x 60 x 28 mm
Speed :
- At Duty Cycle 20%: 150010% RPM
- At Duty Cycle 50%: 350010% RPM
- At Duty Cycle 100%: 7000 RPM
Bearing : Double-Ball
Rated Voltage : 12V
Power :
- At Duty Cycle 20%: 0.6 W
- At Duty Cycle 50%: 2.16 W
- At Duty Cycle 100%: 7.2 W
AIr Flow :
- At Duty Cycle 20%: 8.8 CFM
- At Duty Cycle 50%: 20.3 CFM
- At Duty Cycle 100%: 40.5 CFM
Noise Level :
- At Duty Cycle 20%: 16.0 dBA
- At Duty Cycle 50%: 32.9 dBA
- At Duty Cycle 100%: 47.5 dBA
Air Pressure :
- At Duty Cycle 20%: 0.7 mm-H2O
- At Duty Cycle 50%: 3.6 mm-H2O
- At Duty Cycle 100%: 14.3 mm-H2O
Lead Wire Pin Out :
- Pin1- (-)
- Pin2- (+)
- Pin3- (Techometer/Signal output)
- Pin4- (PWM)

General Information

Manufacturer	ACTi Corporation
Manufacturer Part Number	A24
Manufacturer Website Address	http://www.acti.com
Brand Name	ACTi
Product Model	A24
Product Name	Box Camera
Product Type	Network Camera
UPC	859300007277

Network (RJ-45)	Yes

Height	2.3"
Width	2.4"
Depth	5.6"
Weight (Approximate)	14.78 oz

Warranty

Limited Warranty	3 Year
