Altronix DTMR1 Digital Timer
Model DTMR1 programmable timer is suitable for many functions that require a timed operation e.g. Access Control Applications, Siren/Bell Cut Off Module, Dialer Delay, Guard Tour Supervisory Timer, etc. Some optional functions include: One Shot, Delayed Release, Delayed Operate, Delayed Pulse and Pulser/Flasher. A new feature has been added which provides a momentary relay activation at the end of a desired timing cycle. This feature eliminates the need for having to use two (2) timers to achieve this function. Another new feature will cancel (interrupt) timing cycle and reset timer if desired.
- Includes Snap Track and mounting clips.
- 12VDC or 24VDC operation, SPDT contacts rated @ 8 amp/115VAC.
- 1 sec. to 60 min. adjustable timing range. One second momentary relay activation at the end of timing cycle.
- DIN Rail Mountable Multi-Function Timer.
Product Type: Digital Timer
Environmentally Friendly: Yes
Environmental Certification: RoHS
Country Of Origin: United States
Brand Name: Altronix
Manufacturer: Altronix Corporation
Product Model: DTMR1
Product Name: DTMR1 Digital Timer
Manufacturer Part Number: DTMR1
Manufacturer Website Address: http://www.altronix.com
Packaged Quantity: 1
Package Contents:
- DTMR1 Digital Timer
- Snap Track
- Mounting Clips
- Battery Leads
Limited Warranty: Lifetime
Weight (Approximate): 4.80 oz
