Dell PERC H710P Integrated RAID Controller - Storage controller (RAID) - 8 Channel - SATA 6Gb/s / SAS 6Gb/s - RAID RAID 0, 1, 5, 6, 10, 50, 60 - PCIe 2.0 x8 - for PowerEdge R320, R420, R520, R620, R720, R820, T620
- Incorporates 1 GB of integrated DDR3 cache for quick storage
- Supports RAID levels 0/1/10/5/50/6/60 for storage strategies
The PERC H710 a mid-range Internal RAID solution based on LSI's Thunderbolt (2208) ROC from Dell, which offers dual PPC 600 MHz cores (without fast path support), along with 6 Gb/s SAS. The PERC H710 adapter comes with 1 GB of integrated 1333 MHz DDR3 cache for quick storage. This PCIe 2.0 based card supports PowerEdge internal storage. The PERC H710 operates on PERC 8.0 FW stack and supports RAID levels 0/1/10/5/50/6/60.
-
Enterprise data protection
Standard support for the most popular RAID levels and accessories, further strengthen the data-protection capabilities of the PERC H710P. Dell's NVCache technology backs up the data to nonvolatile storage in a power-loss event, and can store it safely for a nearly unlimited period of time.
-
Intuitive RAID management utility
Dell OpenManage Storage Services (OMSS) provides the essential tools to efficiently manage PERC products, whether deployed in an enterprise or small business. Dell offers a collection of applications and tools, including a pre-boot setup utility and a full spectrum of online RAID management utilities. This suite of applications allow administrators to adjust SAS or SATA topology views from the system host, controller and disk enclosure down to the logical and physical drive level. Extending to enterprise deployments, these tools can scale to easily configure, monitor and manage RAID and JBOD volumes locally or over the LAN network.
