Mellanox ConnectX-5 EN 50Gigabit Ethernet Card
Intelligent RDMA-enabled, single and dual-port network adapter with advanced application offload capabilities for Web 2.0, Cloud, Storage, and Telco platforms
ConnectX-5 Ethernet adapter cards provide high performance and flexible solutions with up to two ports of 100GbE connectivity and 750ns latency. For storage workloads, ConnectX-5 delivers a range of innovative accelerations, such as Signature Handover (T10-DIF) in hardware, an embedded PCIe Switch, and NVMe over Fabric target offloads. ConnectX-5 adapter cards also bring advanced Open vSwitch offloads to telecommunications and cloud data centers to drive extremely high packet rates and throughput with reduced CPU resource consumption, thus boosting data center infrastructure efficiency.
ConnectX-5 adapter cards are available for PCIe Gen 3.0 and Gen 4.0 servers and provide support for 1, 10, 25, 40, 50 and 100 GbE speeds in stand-up PCIe cards, OCP 2.0, and OCP 3.0 form factors. ConnectX-5 cards also offer advanced Mellanox Multi-Host® and Mellanox Socket Direct® technologies.
Cloud and Web 2.0 Environments
ConnectX-5 adapter cards enable data center administrators to benefit from better server utilization and reduced costs, power usage, and cable complexity, allowing for more virtual appliances, virtual machines (VMs) and tenants to co-exist on the same hardware.
Supported vSwitch/vRouter offload functions include:
- Overlay Networks (e.g., VXLAN, NVGRE, MPLS, GENEVE, and NSH) header encapsulation &
- decapsulation.
- Stateless offloads of inner packets and
- packet headers' re-write, enabling NAT
- functionality and more.
- Flexible and programmable parser and
- match-action tables, which enable
- hardware offloads for future protocols.
- SR-IOV technology, providing dedicated
- adapter resources, guaranteed
- isolation and protection for virtual
- machines (VMs) within the server.
- Network Function Virtualization (NFV), enabling a VM to be used as a virtual appliance. The full datapath operation offloads, hairpin hardware capability and service chaining enables data to be handled
- by the virtual appliance, with minimum CPU utilization.
Cloud and Web 2.0 customers developing platforms on Software Defined Network (SDN) environments are leveraging their servers' Operating System Virtual-Switching capabilities to achieve maximum flexibility. Open vSwitch (OvS) is an example of a virtual switch that allows Virtual Machines to communicate with each other and with the outside world. Traditionally residing in the hypervisor where switching is based on twelve-tuple matching onflows, the virtual switch, or virtual router software-based solution, is CPU-intensive. This can negatively affect system performance and prevent the full utilization of available bandwidth.
- Without any additional costs, move to a higher performance technology of 50Gigabit Ethernet card in order to cater to your increased bandwidth requirements
- Enjoy superfast data transfer of up to 16000 MB/s with PCI Express 3.0 x16 card, between the network card and motherboards
- Add your computer to your home or office network with this single port 50gigabit ethernet card conveniently
- Supports optical fiber cable to span longer distances and provides data transmission rates par excellence between servers and network components
- With the 1000Base-X technology get up to 1000Mbps data transfer rate over the supported network cable
Product Type: 50Gigabit Ethernet Card
Environmentally Friendly: Yes
Environmental Certification: RoHS
Brand Name: Mellanox
Form Factor: Plug-in Card
Manufacturer: Mellanox Technologies Ltd
Product Name: ConnectX-5 EN 50Gigabit Ethernet Card
Product Line: ConnectX-5 EN
Manufacturer Part Number: MCX545B-GCUN
Manufacturer Website Address: http://www.mellanox.com
Limited Warranty: 1 Year
