Comprehensive HDMI 4K (18Gbps) Audio Extractor with HDCP 2.2
Comprehensive's HDMI 18Gbps Audio Extractor removes audio signals from any HDMI compliant source to digital optical or analog stereo L/R audio outputs. Both input and output support HDMI video resolution up to 4K2K@50/60Hz (YUV444). It supports 10-bit HDR (High Dynamic Range) pass through and HDMI high resolution digital audio formats bypass, LPCM 2CH, Dolby® True HD, Dolby® Digital Plus, Dolby® Atmos and DTS-HD Master Audio, audio sampling rate up to 192 kHz. HDCP 2.2 and CEC bypass are also supported. This device is perfect for de-embedding audio from devices such as, Apple TV (4th gen), Google Chromecast, Xbox One, PS4, and Sonos Speaker systems. Unit comes with a 3 Year hassle free warranty.
- HDMI 2.0b (18Gbps), HDCP 2.2 and DVI compliant
- Bit stream audio switching
- Video resolutions up to 4K2K@50/60Hz (YUV444)
- Extracts HDMI audio to multi-channel optical (SPDIF) or L/R analog audio
- Optical audio supports LPCM 2CH, Dobly Digital 2/5.1CH, DTS 2/5.1CH
- Supports HDMI High Bit Rate(HBR) audio pass through
- Audio sample rates up to 192kHz
- 10bit HDR (High Dynamic Range) pass through
- Supports CEC bypass
- RoHS Certified
- 3 Year Warranty
Product Type: Signal Extractor
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Condition: New
Brand Name: Comprehensive
Form Factor: External
Manufacturer: Comprehensive Connectivity Company
Product Name: HDMI 4K (18Gbps) Audio Extractor with HDCP 2.2
Manufacturer Part Number: CPA-HDA3
Manufacturer Website Address: http://www.comprehensiveco.com
Packaged Quantity: 1
Package Contents:
- HDMI 4K (18Gbps) Audio Extractor with HDCP 2.2
- 1 x 5V/1A DC Power Adaptor
- Operation Manual
Limited Warranty: 3 Year
Weight (Approximate): 0.29 lb
