ComNet Video Receiver/Data Transceiver
The ComNet FVT/FVR107 series of optical video links provides 10-bit Digitally Encoded video, 10 Mhz bandwidth, short haul video quality, one bi-directional data channel and a dual optical port redundant Point-to-Point topology plus eight contact closures and two alarm relays. The redundant Point-to-Point topology using the dual optical ports provide fail safe operation in the event of loss of one fiber. Each optical port uses wavelength division multiplexing (WDM) to both transmit and receive on one optical fiber. Microprocessor-based logic sends the contact information in packets that are ordered and encoded, ensuring extremely robust transmission. Packets that are garbled, packets out of sequence, and transmission bit errors will not cause random changes of state on the contact relays. Also, the mechanical latching relays maintain their state even when the unit loses power. The data channel supports RS232, RS422 and 2 wire and 4 wire RS485.
Features for FVT/FVR107 Series
- Microprocessor-based logic and latching relays in receiver unit eliminate random contact closure status in the event of loss of link or loss of prime operating power.
- Automatic resettable fuses on all power lines
- Status indicating LEDs provide rapid indication of critical operating parameters.
- Bi-directional data channel supports RS232, RS422 or RS485 (2 or 4-wire) interfaces.
- Lifetime Warranty
- Made in the USA
- Distances up to 30 miles (48 km)
- Eight SPST latching relays (with individual LED indicators)
- Two separate alarm relay outputs indicate when a fiber link is lost and which optical port.
- Dual optical port Redundant Point-to-Point (RPP) configuration
- Designed for installation in harsh out-of-plant/unconditioned industrial or roadside operating environments (-40 to +75C ambient). Fully compliant with the environmental requirements of NEMA TS-2 for Traffic Signal Control Equipment
- Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events.
- Compatible with NTSC, PAL, or SECAM Video Standards
- 10-bit digitally encoded short-haul video transmission meets the requirements of the EIA RS-250C standard.
- Standard ComFit models are hot-swappable.
- ComFit standard form factor is designed for wall, surface, rack, or DIN rail mount installations (using optional card cage or DIN mounting bracket).
Product Type: Video Extender Transceiver
Environmentally Friendly: Yes
Environmental Certification: WEEE
Receiver Height: 2.20"
Receiver Width: 5.30"
Receiver Depth: 6.10"
Country Of Origin: United States
Product Series: FVT/FVR107(M,S)1
Brand Name: ComNet
Manufacturer: ACRE
Product Model: FVR107M1
Product Name: Video Receiver/Data Transceiver
Manufacturer Part Number: FVR107M1
Manufacturer Website Address: http://www.acre-co.com
Package Contents:
- Video Receiver/Data Transceiver
- 9 Volt DC Plug-in Power Supply
Limited Warranty: Lifetime
