ComNet Small Form-Factor Pluggable Long Reach Ethernet Over VDSL2
The ComNet SFP-VDSLAB small form-factor pluggable Ethernet extender module kit improves bandwidth and distance of Ethernet over existing VDSL2 technology. It helps avoid installation costs of new fiber lines on site and can extend Ethernet service on UTP wire with distance up to 3,000 meters. Full Duplex 100 Mbps speed can reach up to 400 meters over standard Cat 5e 2-wire cable. The symmetric profile can be used for standard Ethernet connections or the asymmetric profile can support high traffic flow in a single direction.
Housed in a small form-factor pluggable (SFP) module enclosure, it is designed for plug-and-play installation into any 1000BASE-FX Ethernet unit with an MSA-compliant port. These pairs include the SFP-VDSLA module to be installed at one end and the SFP-VDSLB installed in the other.
- Extends Ethernet up to 1.8 mi (3 km) (see distance/ bandwidth table on page 2) and can support 1,300 ft (400 m) at 100 Mbps over Cat 5e 2-wire cable.
- Small Form-Factor Pluggable (SFP) module can be plugged into any Ethernet switch with SFP ports that support 1000BASE-FX
- Designed to meet full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/lowline voltage conditions and transient voltage protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment.
- Lifetime Warranty
Product Type: SFP (mini-GBIC)
Environmentally Friendly: Yes
Environmental Certification: WEEE
Brand Name: ComNet
Compatibility: MSA Compliant
Manufacturer: ACRE
Product Name: Small Form-Factor Pluggable Long Reach Ethernet Over VDSL2
Manufacturer Part Number: SFP-VDSLAB
Manufacturer Website Address: http://www.acre-co.com
Limited Warranty: Lifetime
Weight (Approximate): 0.07 lb
