ComNet RLMC1005(M,S)2 Transceiver/Media Converter
The ComNet RLMC1005 Series is a substation-rated and industrially hardened Ethernet media converter. Fully compliant with the requirements of IEC 61850-3, IEEE 1613 Class 2, UL 508 Class 1/ Division 2 (Groups A, B, C, & D for hazardous environments), EN50155, and NEMA TS-1/TS-2, it is designed for deployment in environments where high levels of electromagnetic noise and interference (EMI) and severe voltage transients and surges are routinely encountered, such as electrical utility substations and switchyards, heavy manufacturing facilities, trackside and roadside electronic equipment, and other difficult out-of-plant applications. The DIP-switch-selectable 100BASE-FX or 1000BASE-FX port supports conventional CAT-5e/CAT-6 copper or optical transmission media by selection of the appropriate ComNet SFP* module or fixed 2 fiber ST or SC optical connectors. User-selectable link fault pass-through provides remote indication of a network fault, and a summary fault alarm provides a local or remote indication via a dry contact closure in the event of loss of optical link or operating power. The 10/100/1000BASE-TX port supports both auto-negotiation and automatic MDI/MDI-X crossover for full and half-duplex operation; manual MDI/MDI-X switching is not required.
The internal/self-contained 12 to 24 VDC, 48 VDC, or HV AC/DC power supply features redundant power inputs when used with 12 to 24 VDC, or 48 VDC power sources, for the highest possible reliability. The simple plug-and-play RLMCSFP is DIN-rail or panel-mountable, and is ideal for mission-critical applications where very high levels of reliability and network availability are of the utmost importance.
- Link fault pass-through provides a remote indication of a network fault
- 12 to 24 VDC, 48 VDC or HV AC/DC (88 to 300 VDC/85-264 VAC) operating power options
- Internal/self-contained high-reliability power supply eliminates the need for an external power supply, and a screw terminal block connects directly to the power source for permanent, reliable, and maintenance-free operation
- Status indicating LEDs provide rapid indication of critical operating parameters.
- Summary fault alarm provides a local or remote indication via a dry contact closure in the event of loss of optical link or operating power
- Rugged 19-gauge galvanized and powder-coated steel enclosure.
- Made in the USA
- Full duplex transmission of 10/100 Mbps Ethernet: (1) 10/100BASE-TX port and (1) 100BASE-FX 2 Fiber ST optical port (Multimode or Single Mode)
- Designed to the requirements of IEC 61850-3 and IEEE 1613 Class 2 for electrical utility substations, EN50155 and EN50121-4 for railway applications, and NEMA TS-1/TS-2 for traffic signal control equipment and IEC/EN60950-1
- Extended ambient operating temperature range of -40 to +85 C, for use in virtually any environment. Optional conformal coating available for humidity with condensation or airborne particulate matter environments
Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: WEEE
Country Of Origin: United States
Product Series: RLMC1005(M,S)2
Brand Name: ComNet
Form Factor: Panel-mountable
Manufacturer: ACRE
Product Name: RLMC1005(M,S)2 Transceiver/Media Converter
Manufacturer Part Number: RLMC1005M2/24DC
Manufacturer Website Address: http://www.acre-co.com
Package Contents:
- RLMC1005(M,S)2 Transceiver/Media Converter
- Panel-mounting Adapter
Limited Warranty: Lifetime
Weight (Approximate): 1.50 lb
