ComNet Electrical Substation-Rated 10/100/1000 Mbps 3-Port Self-managed Ethernet Switch
The ComNet RLGE2+1SMSPOEHO is a substation-rated and industrially hardened 3-port self-managed Ethernet switch with uplink management capability, that supports Universal PoE (Power over Ethernet) powered devices requiring up to 60 watts of operating power. Designed to the requirements of IEC 61850-3, IEEE 1613 Class 2, EN50155, and NEMA TS-1/TS-2, it is intended for deployment in environments where high levels of electromagnetic noise and interference (EMI) and severe voltage transients and surges are routinely encountered, such as electrical utility substations and switchyards, heavy manufacturing facilities, trackside and roadside electronic equipment, and other difficult out-of-plant applications. User-selectable link fault pass-through provides remote indication of a network fault, and two summary fault alarms provide a local or remote indication via dry contact closures in the event of loss of optical link or operating power. The 10/100/1000BASE-TX ports support both autonegotiation and automatic MDI/MDI-X crossover for full and half-duplex operation; manual MDI/MDI-X switching is not required. The RLGE2+1SMSPOEHO comes pre-programmed, preventing network video flooding with DIP-switch selection of the SFP port as uplink or as an unmanaged switch. The internal/self-contained power supply features redundant 48 VDC inputs, for the highest possible reliability. The simple to install, plug-and-play RLGE2+1SMSPOEHO is DIN-rail or panel-mountable, and is ideal for mission-critical applications where very high levels of reliability and network availability are of the utmost importance.
FEATURES:
- Supports PoE PDs (Powered Devices) requiring PoE (15 watts), PoE+ (30 watts), and Universal PoE/PoE++ (60 watts)
- Full duplex transmission of 10/100/1000 Mbps Ethernet: (2) 10/100/1000BASE-TX ports and (1) 100BASE-FX or 1000BASE-FX SFP port
- Designed to the requirements of IEC 61850-3 and IEEE 1613 Class 2 for electrical utility substations, EN50155 for railway applications, and NEMA TS-1/TS-2 for traffic signal control equipment, and IEC/EN60950-1
- Extended ambient operating temperature range of -40 to +85 C, for use in virtually any environment. Optional conformal coating available for humidity with condensation or airborne particulate matter environments
- Uses customer-installed ComNet SFPs for compatibility with a wide range of optical fibers, optical connector types, and optical transmission distances of up to 120 km
- Link fault pass-through provides a remote indication of a network fault
- 10/100/1000BASE-TX ports support both auto-negotiation and automatic MDI/MDI-X crossover for full and half-duplex operation; manual MDI/MDI-X switching is not required
- 48 VDC operating power
- Internal/self-contained high-reliability power supply eliminates the need for an external power supply, and a screw terminal block connects directly to the power source for permanent, reliable, and maintenance-free operation
- Features redundant power inputs, for extremely high levels of reliability and availability
- No fans or forced-air cooling required; cooling via natural convection eliminates unreliable and troublesome fans/moving parts for improved reliability
- Indicating LEDs confirm operating status of the switch and the link for ease in troubleshooting
- Summary fault alarm provides a local or remote indication via dry contact closure in the event of loss of optical link or operating power
- Rugged 19-gauge galvanized & powder-coated steel enclosure may be DIN-rail or panel-mounted
- Made in the USA
- Lifetime Warranty
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 3 ports
- Cascade to other network devices through the uplink port to expand your local area network
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Gigabit Ethernet port for ultra-fast network speeds
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Management capability provides control over setup and configuration of your network
- Built-in power supply to ensure all components are being supplied with accurate voltage
Product Type: Ethernet Switch
Environmentally Friendly: Yes
Environmental Certification: WEEE
Country Of Origin: United States
Brand Name: ComNet
Form Factor: Wall Mountable
Manufacturer: ACRE
Product Model: RLGE2+1SMSPOEHO
Product Name: Electrical Substation-Rated 10/100/1000 Mbps 3-Port Self-managed Ethernet Switch
Manufacturer Part Number: RLGE2+1SMSPOEHO
Manufacturer Website Address: http://www.acre-co.com
Package Contents:
- Electrical Substation-Rated 10/100/1000 Mbps 3-Port Self-managed Ethernet Switch
- Panel Mounting Adaptor Plate Kit with Mounting Hardware
- DIN Rail Mounting Adaptor Clip Kit with Mounting Hardware
Limited Warranty: Lifetime
Weight (Approximate): 1.50 lb
